bool RecastInterface::buildNavMesh(InputGeometry* inputGeom)
{


	//Step 1 : Initialize build configuration
	//Start the timers.

#ifdef _DEBUG
	std::cout << "NavMesh build started." << std::endl;
	unsigned long start = Ogre::Root::getSingleton().getTimer()->getMilliseconds();
	unsigned long end = 0;
#endif

	//Step 2 : Rasterize input polygon soup
	//InputGeometry* input = inputGeom; WTF? Is this necessary?
	rcVcopy(_config.bmin, inputGeom->getMeshBoundsMin());
	rcVcopy(_config.bmax, inputGeom->getMeshBoundsMax());
	rcCalcGridSize(_config.bmin,_config.bmax,_config.cs,&_config.width,&_config.height);

	int numVerts = inputGeom->getVertexCount();
	int numTris = inputGeom->getTriangleCount();

#ifdef _DEBUG
	Ogre::Vector3 min,max;
	Utility::floatPtr_toVector3(inputGeom->getMeshBoundsMin(),min);
	Utility::floatPtr_toVector3(inputGeom->getMeshBoundsMax(),max);
	std::cout << "Bounds: min=" << min << " max=" << max << std::endl;

	std::cout << "Building navmesh" << std::endl;
	std::cout << " - " << _config.width << " x " << _config.height << std::endl;
	std::cout << " - " << numVerts / 1000.0f << "K vertices, ";
	std::cout << numTris / 1000.0f << "K triangles" << std::endl;

	//_printConfig();
#endif

	_solid = rcAllocHeightfield();
	if(!_solid)
	{
		std::cout << "Error! Out of memory needed for '_solid'." << std::endl;
		return false;
	}
	if(!rcCreateHeightfield(_context,*_solid,
							_config.width,_config.height,
							_config.bmin,_config.bmax,
							_config.cs,_config.ch))
	{
		std::cout << "Error! Couldn't create heightfield, try higher cellSize and cellHeight values." << std::endl;
		return false;
	}

	//holds triangle area types
	_triangleAreas = new unsigned char[numTris];
	if(!_triangleAreas)
	{
		std::cout << "Error! Out of memory '_triangleAreas'([" << numTris << "])" << std::endl;
		return false;
	}

	//find triangles that are walkable in slope and rasterize them
	memset(_triangleAreas,0,numTris * sizeof(unsigned char));
	rcMarkWalkableTriangles(_context,_config.walkableSlopeAngle,
							inputGeom->getVertices(),inputGeom->getVertexCount(),
							inputGeom->getTriangles(),inputGeom->getTriangleCount(),
							_triangleAreas);
	rcRasterizeTriangles(_context,inputGeom->getVertices(),inputGeom->getVertexCount(),
						 inputGeom->getTriangles(),_triangleAreas,
						 inputGeom->getTriangleCount(),*_solid,_config.walkableClimb);

	//I know I put this option in the params, but...
	if(!_recastParams.getKeepIntermediateResults())
	{
		delete[] _triangleAreas;
		_triangleAreas = nullptr;
	}

	//Step 3 : Filter walkables surfaces
	//Initial pass of filtering to remove unwanted overhangs caused
	//by the conservative rasterization.
	//Also filters spans where the character can't stand.
	rcFilterLowHangingWalkableObstacles(_context,_config.walkableClimb,*_solid);
	rcFilterLedgeSpans(_context,_config.walkableHeight,_config.walkableClimb,*_solid);
	rcFilterWalkableLowHeightSpans(_context,_config.walkableHeight,*_solid);

	//Step 4 : Partition walkable surface to simple regions
	//Compact the heightfield so that it is faster to handle from now on.
	_compactHeightfield = rcAllocCompactHeightfield();
	if(!_compactHeightfield)
	{
		std::cout << "Error! Out of memory '_compactHeightfield'" << std::endl;
		return false;
	}
	if(!rcBuildCompactHeightfield(_context,
								  _config.walkableHeight,_config.walkableClimb,
								  *_solid,*_compactHeightfield))
	{
		std::cout << "Error! BuildNav - Could not build compact data." << std::endl;
		return false;
	}

	if(!_recastParams.getKeepIntermediateResults())
	{
		rcFreeHeightField(_solid);
		_solid = nullptr;
	}

	//Erode walkable area by agent radius
	if(!rcErodeWalkableArea(_context,_config.walkableRadius,*_compactHeightfield))
	{
		std::cout << "Error! BuildNav - Could not erode walkable areas." << std::endl;
		return false;
	}

	//Prepare for region partitioning, generate distance field
	if(!rcBuildDistanceField(_context,*_compactHeightfield))
	{
		std::cout << "Error! BuildNav - Could not build distance field." << std::endl;
		return false;
	}

	//Partition the walkable surface into simple regions w/o holes
	if(!rcBuildRegions(_context,*_compactHeightfield,
					   _config.borderSize,
					   _config.minRegionArea,_config.mergeRegionArea))
	{
		std::cout << "Error! BuildNav - Could not build regions." << std::endl;
		return false;
	}

	//Step 5 : Trace and simplify region contours.
	//create contours
	_contourSet = rcAllocContourSet();
	if(!_contourSet)
	{
		std::cout << "Error! BuildNav - Out of memory '_contourSet'" << std::endl;
		return false;
	}

	if(!rcBuildContours(_context,*_compactHeightfield,_config.maxSimplificationError,_config.maxEdgeLen,*_contourSet))
	{

		std::cout << "Error! BuildNav - Could not create contours." << std::endl;
		return false;
	}

	if(_contourSet->nconts == 0)
	{
		//Check this thread for details on solving these:
		//http://groups.google.com/group/recastnavigation/browse_thread/thread/a6fbd509859a12c8
		std::cout << "Error! BuildNav - RecastNav created no contours!" << std::endl;
		std::cout << _compactHeightfield->spanCount << std::endl;
	}

	//Step 6 : Build polygons mesh from contours
	//Build polygon navmesh from the contours
	_polyMesh = rcAllocPolyMesh();
	if(!_polyMesh)
	{
		std::cout << "Error! Out of memory '_polyMesh'." << std::endl;
		return false;
	}

	if(!rcBuildPolyMesh(_context,*_contourSet,_config.maxVertsPerPoly,*_polyMesh))
	{
		std::cout << "Error! BuildNav - Could not triangulate contours." << std::endl;
	}

	//Step 7 : Create detail mesh which allows access to approximate height on each polygon.
	_detailMesh = rcAllocPolyMeshDetail();
	if(!_detailMesh)
	{
		std::cout << "Error! Out of memory '_detailMesh'." << std::endl;
		return false;
	}

	if(!rcBuildPolyMeshDetail(_context,
							  *_polyMesh,*_compactHeightfield,
							  _config.detailSampleDist,_config.detailSampleMaxError,
							  *_detailMesh))
	{
		std::cout << "Error! BuildNav - Could not build detail mesh." << std::endl;
		return false;
	}

	if(!_recastParams.getKeepIntermediateResults())
	{
		rcFreeCompactHeightfield(_compactHeightfield);
		_compactHeightfield = nullptr;

		rcFreeContourSet(_contourSet);
		_contourSet = nullptr;
	}

	//Recast navmesh is finished!
#ifdef _DEBUG
	end = Ogre::Root::getSingletonPtr()->getTimer()->getMilliseconds();
	std::cout << "Navmesh build finished." << std::endl;
	std::cout << " - Time elapsed:" << end - start << "ms" << std::endl;
#endif

	return true;
}
