// Project: Grab
// Created: MR 22.09.2015 22:46

// set window properties
SetWindowTitle( "Grab" )
//SetWindowSize( 1024, 768, 0 )

SetPrintColor(0,0,255)

type TPunkt
	x as float
	y as float
endtype

global Punkt as TPunkt[4]

Main()
end

function Main()

	local i as integer
	local sprnr as integer[4]
	for i=1 to 4
		sprnr[i]=LoadSprite(str(i)+".png")  //number images 1-4
		SetSpriteSize(sprnr[i],5,5)
		SetSpritePosition(sprnr[i],5+i*5,5)
		SetSpriteDepth(sprnr[i],10)
	next

	local spr
	spr = LoadSprite("temp.jpg") 	//any example image
	SetSpriteDepth(spr,20)
	SetSpriteSize(spr,-1.0,100.0)

	local p=1

	do

		//... Image Dialog

		if GetPointerReleased()
			p=p+1
			if p>4 then p=1
		endif
		if GetPointerState()=1
			x#=GetPointerX()
			y#=GetPointerY()
			Punkt[p].x=x#
			Punkt[p].y=y#
		endif

		//aktivate point 1-4 with key 1-4
		if GetRawKeyPressed(49) then p=1
		if GetRawKeyPressed(50) then p=2
		if GetRawKeyPressed(51) then p=3
		if GetRawKeyPressed(52) then p=4

		//Enter
		if GetRawKeyPressed(13)
			for i=1 to 4
				SetSpriteVisible(sprnr[i],0)
			next
			Get(spr)
			Ready()
			for i=1 to 4
				SetSpriteVisible(sprnr[i],1)
			next
			sync()
		endif

		Lines(Punkt,sprnr)

		Sync()
	loop

endfunction


function Lines(Punkt as TPunkt[],sprnr as integer[])

	local col as integer
	col= MakeColor(255,255,0)

	Drawline(Punkt[1].x,Punkt[1].y,Punkt[2].x,Punkt[2].y,col,col)
	Drawline(Punkt[2].x,Punkt[2].y,Punkt[3].x,Punkt[3].y,col,col)
	Drawline(Punkt[3].x,Punkt[3].y,Punkt[4].x,Punkt[4].y,col,col)
	Drawline(Punkt[4].x,Punkt[4].y,Punkt[1].x,Punkt[1].y,col,col)

	for i=1 to 4
		SetSpritePosition(sprnr[i],Punkt[i].x,Punkt[i].y)
	next

endfunction

function Linear(p1 as TPunkt, p2 as TPunkt, mu as float)

	local pn as TPunkt

    pn.x = LinearInterpolate(p1.x,p2.x,mu)
    pn.y = LinearInterpolate(p1.y,p2.y,mu)

endfunction pn

function LinearInterpolate( y1 as float, y2 as float, mu as float)

	local f as float
	f=(y1*(1.0-mu)+y2*mu)

endfunction f

function Get(spr as integer)
	local pa as TPunkt
	local pb as TPunkt
	local pc as TPunkt
	local a as float
	local b as float
	local x as float
	local y as float

	//----------------------

	local width as float
	local height as float
	width=512				//<<< Output Texture Size
	height=512
	format=0
	mipmap=0
	depthImage=0

	colorImage=CreateRenderImage ( width, height, format, mipmap )
	memblock=CreateMemblockFromImage(colorImage)

	deleteimage(colorImage)

	//----------------------

	//C:\Users\Gang\AppData\Local\AGKApps\GrabTexture\media

	local col as integer
	col= MakeColor(255,0,0)

	local size as float
	size=1.0 // / 100.0

	for x=0 to width-1.0
	a=x / (width-1.0)
	pa=Linear(Punkt[1],Punkt[2],a)
	pb=Linear(Punkt[4],Punkt[3],a)

	render() //nach dem Sync ist der Backbuffer leer!

	for y=0 to height-1.0
		b=y / (height-1.0)
		pc=Linear(pa,pb,b)
		//------------------------
		imageID=GetImage(pc.x,pc.y,size,size) //get from backbuffer
		memtemp=CreateMemblockFromImage(imageID) //make image data
		col=GetMemblockInt(memtemp,12) //first Pixel
		//col = col + 0xFF000000
		offset=12.0+(x*4+(y*width*4))
		SetMemblockInt(memblock,offset,col) //write pixel to texture data
		DeleteMemblock(memtemp)
		DeleteImage(imageID)
		//------------------------
	next
	next

	//----------------------

	colorImage=CreateImageFromMemblock(memblock)
	DeleteMemblock(memblock)

	SaveImage( colorImage, "grab.png" )

	DeleteImage(colorImage)

endfunction

function Ready()

	do

		print("Ready. Click anywhere.")

		if GetPointerPressed() then exit
		sync()
	loop

endfunction
