I have finally made some thorough testing of how Oculus Rift work with various AGKVR commands.
To approach this seriously, I wrote a program which displays all the AGKVR information I could find:

// Project: HMD data
// Created: 2018-03-21

// show all errors
SetErrorMode(2)

// set window properties
SetWindowTitle( "HMD data" )
SetWindowSize( 1024, 1024, 0 )
SetWindowAllowResize( 1 ) // allow the user to resize the window

// set display properties
SetVirtualResolution( 1024, 1024 ) // doesn't have to match the window
SetAntialiasMode( 1 ) // 1=4xMSAA
SetSyncRate( 90, 0 )
SetScissor( 0,0,0,0 ) // use the maximum available screen space, no black borders
UseNewDefaultFonts( 1 ) // since version 2.0.22 we can use nicer default fonts

//Load the AGKVR plugin
#import_plugin AGKVR

/*===============================================================================
   VR TECH STUFFIE
===============================================================================*/

//Set the Camera Range in AGKVR
//It is necessary to use this command for setting the camera's range instead of the standard AGK SetCameraRange command
//AGKVR.SetCameraRange( 0.01, 1000.0 )
AGKVR.SetCameraRange( 0.01, 1000.0 )

//Initialiaze AGKVR
// The parameters are the Right and Left Eye image ID's that will be used to render to the HMD
InitError As Integer
RightEyeImg As Integer = 500
LeftEyeImg As Integer = 501
InitError = AGKVR.Init( RightEyeImg, LeftEyeImg )
// InitError = 0: SUCCESS!
// InitError = 1: Unable to init VR runtime
// InitError = 2: Compositor initialization failed.

//This command will lock the player's heading direction
//to follow the turn angle of the HMD. This would be common in FPS games, where
//you want the forward moving direction's turn angle to change based on where the
//player is looking. LockPlayerTurn is ON(1) by default
AGKVR.LockPlayerTurn( 1 )

//This command will lock the player's heading direction (forward on the Z axis)
//to follow the pitch angle of the HMD. This would be useful in a freeflight style game
//where you want the forward moving direction's pitch angle to change based on where the
//player is looking. LockPlayerPitch is OFF(0) by default
AGKVR.LockPlayerPitch( 0 )

myStr as String

myText = CreateText(myStr)
SetTextPosition ( myText, 10, 10 )
SetTextSize ( myText, 25 )
SetTextVisible( myText, 0 )
SetTextColor( myText, 0, 0, 0, 255 )
SetTextMaxWidth( myText, 800 )

theFont = LoadFont( "Now-Medium.otf" )
SetTextFont( myText, theFont )

/*===============================================================================
   DISPLAYED TEXT
===============================================================================*/

screen2D = CreateObjectPlane( 1.024, 1.024 )

SetObjectPosition(screen2D, 0.0, 1.8, 0.6)
setObjectRotation (screen2D, 0, 0, 0)

screen2DImg = CreateRenderImage (1600,1600,0,0)

dataInput = 1 // the kind of input displayed at the monitor

do

	// Escape to exit
	if GetRawKeyPressed(27)
		AGKVR.Shutdown()	// Clean shutdown
		End
	endif

if GetRawKeyPressed(49) then dataInput = 1 // 1 === SETUP COMMANDS:
	if GetRawKeyPressed(50) then dataInput = 2 // 2 === PLAYER COMMANDS:
	if GetRawKeyPressed(51) then dataInput = 3 // 3 === CONTROLLER COMMANDS: (LEFT)
	if GetRawKeyPressed(52) then dataInput = 4 // 4 === CONTROLLER COMMANDS: (RIGHT)
	if GetRawKeyPressed(53) then dataInput = 5 // 5 === CHAPERONE COMMANDS:
	if GetRawKeyPressed(54) then dataInput = 6 // 6 === DEVICE INFO COMMANDS:

if dataInput = 1
		myStr = "SETUP COMMANDS:" + Chr(10) + Chr(10)
		myStr = myStr + "HMD present: " + trueFalse(AGKVR.IsHmdPresent()) + Chr(10)
		myStr = myStr + "Runtime installed: " + trueFalse(AGKVR.IsRuntimeInstalled()) + Chr(10)
		myStr = myStr + "Tracking space: " + seatedStanding(AGKVR.GetTrackingSpace()) + Chr(10)
		myStr = myStr + "World scale: " + str(AGKVR.GetWorldScale()) + Chr(10)
	endif

if dataInput = 2
		myStr = "PLAYER COMMANDS:" + Chr(10) + Chr(10)
		myStr = myStr + "Player X position: " + str(AGKVR.GetPlayerX()) + Chr(10)
		myStr = myStr + "Player Y position: " + str(AGKVR.GetPlayerY()) + Chr(10)
		myStr = myStr + "Player Z position: " + str(AGKVR.GetPlayerZ()) + Chr(10)
		myStr = myStr + "Player X angle: " + str(AGKVR.GetPlayerAngleX()) + Chr(10)
		myStr = myStr + "Player Y angle: " + str(AGKVR.GetPlayerAngleY()) + Chr(10)
		myStr = myStr + "Player Z angle: " + str(AGKVR.GetPlayerAngleZ()) + Chr(10)
		myStr = myStr + "HMD X position: " + str(AGKVR.GetHMDX()) + Chr(10)
		myStr = myStr + "HMD Y position: " + str(AGKVR.GetHMDY()) + Chr(10)
		myStr = myStr + "HMD Z position: " + str(AGKVR.GetHMDZ()) + Chr(10)
		myStr = myStr + "HMD X angle: " + str(AGKVR.GetHMDAngleX()) + Chr(10)
		myStr = myStr + "HMD Y angle: " + str(AGKVR.GetHMDAngleY()) + Chr(10)
		myStr = myStr + "HMD Z angle: " + str(AGKVR.GetHMDAngleZ()) + Chr(10)
		myStr = myStr + "Right hand X position: " + str(AGKVR.GetRightHandX()) + Chr(10)
		myStr = myStr + "Right hand Y position: " + str(AGKVR.GetRightHandY()) + Chr(10)
		myStr = myStr + "Right hand Z position: " + str(AGKVR.GetRightHandZ()) + Chr(10)
		myStr = myStr + "Right hand X angle: " + str(AGKVR.GetRightHandAngleX()) + Chr(10)
		myStr = myStr + "Right hand Y angle: " + str(AGKVR.GetRightHandAngleY()) + Chr(10)
		myStr = myStr + "Right hand Z angle: " + str(AGKVR.GetRightHandAngleZ()) + Chr(10)
		myStr = myStr + "Left hand X position: " + str(AGKVR.GetLeftHandX()) + Chr(10)
		myStr = myStr + "Left hand Y position: " + str(AGKVR.GetLeftHandY()) + Chr(10)
		myStr = myStr + "Left hand Z position: " + str(AGKVR.GetLeftHandZ()) + Chr(10)
		myStr = myStr + "Left hand X angle: " + str(AGKVR.GetLeftHandAngleX()) + Chr(10)
		myStr = myStr + "Left hand Y angle: " + str(AGKVR.GetLeftHandAngleY()) + Chr(10)
		myStr = myStr + "Left hand Z angle: " + str(AGKVR.GetLeftHandAngleZ()) + Chr(10)
	endif


	if dataInput = 3
		myStr = "CONTROLLER COMMANDS:: (LEFT)" + Chr(10) + Chr(10)
		myStr = myStr + "Left controller found: " + trueFalse(AGKVR.LeftControllerFound()) + Chr(10)
		myStr = myStr + "Left controller X axis: " + str(AGKVR.LeftController_JoyX()) + Chr(10)
		myStr = myStr + "Left controller Y axis: " + str(AGKVR.LeftController_JoyY()) + Chr(10)
		myStr = myStr + "Left controller trigger: " + str(AGKVR.LeftController_Trigger()) + Chr(10)
		myStr = myStr + "Left controller grib: " + trueFalse(AGKVR.LeftController_Grip()) + Chr(10) // is it really an integer?	Yes.
		myStr = myStr + "Left controller button 1: " + trueFalse(AGKVR.LeftController_Button1()) + Chr(10)
		myStr = myStr + "Left controller button 2: " + trueFalse(AGKVR.LeftController_Button2()) + Chr(10)
		myStr = myStr + "Left controller finger pointed: " + trueFalse(AGKVR.LeftController_GetFingerPointed()) + Chr(10)
		myStr = myStr + "Left controller thumbs up: " + trueFalse(AGKVR.LeftController_GetThumbUp()) + Chr(10) //
		myStr = myStr + "Left controller Axis trigger X [0]: " + str(AGKVR.LeftController_AxisTriggerX(0)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger X [1]: " + str(AGKVR.LeftController_AxisTriggerX(1)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger X [2]: " + str(AGKVR.LeftController_AxisTriggerX(2)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger X [3]: " + str(AGKVR.LeftController_AxisTriggerX(3)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger X [4]: " + str(AGKVR.LeftController_AxisTriggerX(4)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger X [5]: " + str(AGKVR.LeftController_AxisTriggerX(5)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger Y [0]: " + str(AGKVR.LeftController_AxisTriggerY(0)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger Y [1]: " + str(AGKVR.LeftController_AxisTriggerY(1)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger Y [2]: " + str(AGKVR.LeftController_AxisTriggerY(2)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger Y [3]: " + str(AGKVR.LeftController_AxisTriggerY(3)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger Y [4]: " + str(AGKVR.LeftController_AxisTriggerY(4)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger Y [5]: " + str(AGKVR.LeftController_AxisTriggerY(5)) + Chr(10)
		myStr = myStr + "buttons:" + Chr(10)
		for allB = 0 to 63
			myStr = myStr + str(allB) + ":" + checkmarks(AGKVR.LeftController_ButtonPressed(allB))
		next
	endif

	if dataInput = 4
		myStr = "CONTROLLER COMMANDS:: (RIGHT)" + Chr(10) + Chr(10)
		myStr = myStr + "Right controller found: " + trueFalse(AGKVR.RightControllerFound()) + Chr(10)
		myStr = myStr + "Right controller X axis: " + str(AGKVR.RightController_JoyX()) + Chr(10)
		myStr = myStr + "Right controller Y axis: " + str(AGKVR.RightController_JoyY()) + Chr(10)
		myStr = myStr + "Right controller trigger: " + str(AGKVR.RightController_Trigger()) + Chr(10)
		myStr = myStr + "Right controller grib: " + trueFalse(AGKVR.RightController_Grip()) + Chr(10) // is it really an integer? Yes.
		myStr = myStr + "Right controller button 1: " + trueFalse(AGKVR.RightController_Button1()) + Chr(10)
		myStr = myStr + "Right controller button 2: " + trueFalse(AGKVR.RightController_Button2()) + Chr(10)
		myStr = myStr + "Right controller finger pointed: " + trueFalse(AGKVR.RightController_GetFingerPointed()) + Chr(10)

myStr = myStr + "Right controller thumbs up: " + trueFalse(AGKVR.RightController_GetThumbUp()) + Chr(10)
		myStr = myStr + "Right controller Axis trigger X [0]: " + str(AGKVR.RightController_AxisTriggerX(0)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger X [1]: " + str(AGKVR.RightController_AxisTriggerX(1)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger X [2]: " + str(AGKVR.RightController_AxisTriggerX(2)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger X [3]: " + str(AGKVR.RightController_AxisTriggerX(3)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger X [4]: " + str(AGKVR.RightController_AxisTriggerX(4)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger X [5]: " + str(AGKVR.RightController_AxisTriggerX(5)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger Y [0]: " + str(AGKVR.RightController_AxisTriggerY(0)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger Y [1]: " + str(AGKVR.RightController_AxisTriggerY(1)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger Y [2]: " + str(AGKVR.RightController_AxisTriggerY(2)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger Y [3]: " + str(AGKVR.RightController_AxisTriggerY(3)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger Y [4]: " + str(AGKVR.RightController_AxisTriggerY(4)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger Y [5]: " + str(AGKVR.RightController_AxisTriggerY(5)) + Chr(10)
		myStr = myStr + "buttons:" + Chr(10)
		for allB = 0 to 63
			myStr = myStr + str(allB) + ":" + checkmarks(AGKVR.RightController_ButtonPressed(allB))
		next
	endif



	if dataInput = 5
		myStr = "CHAPERONE COMMANDS:" + Chr(10) + Chr(10)
		myStr = myStr + "Play area size X: " + str(AGKVR.Chaperone_GetPlayAreaSizeX()) + Chr(10)
		myStr = myStr + "Play area size Z: " + str(AGKVR.Chaperone_GetPlayAreaSizeZ()) + Chr(10)
		myStr = myStr + "Are bounds visible: " + trueFalse(AGKVR.Chaperone_AreBoundsVisible()) + Chr(10)
		myStr = myStr + "play area point 1X: " + str(AGKVR.Chaperone_GetPlayAreaPoint1X()) + Chr(10)
		myStr = myStr + "play area point 1Y: " + str(AGKVR.Chaperone_GetPlayAreaPoint1Y()) + Chr(10)
		myStr = myStr + "play area point 1Z: " + str(AGKVR.Chaperone_GetPlayAreaPoint1Z()) + Chr(10)
		myStr = myStr + "play area point 2X: " + str(AGKVR.Chaperone_GetPlayAreaPoint2X()) + Chr(10)
		myStr = myStr + "play area point 2Y: " + str(AGKVR.Chaperone_GetPlayAreaPoint2Y()) + Chr(10)
		myStr = myStr + "play area point 2Z: " + str(AGKVR.Chaperone_GetPlayAreaPoint2Z()) + Chr(10)
		myStr = myStr + "play area point 3X: " + str(AGKVR.Chaperone_GetPlayAreaPoint3X()) + Chr(10)
		myStr = myStr + "play area point 3Y: " + str(AGKVR.Chaperone_GetPlayAreaPoint3Y()) + Chr(10)
		myStr = myStr + "play area point 3Z: " + str(AGKVR.Chaperone_GetPlayAreaPoint3Z()) + Chr(10)
		myStr = myStr + "play area point 4X: " + str(AGKVR.Chaperone_GetPlayAreaPoint4X()) + Chr(10)
		myStr = myStr + "play area point 4Y: " + str(AGKVR.Chaperone_GetPlayAreaPoint4Y()) + Chr(10)
		myStr = myStr + "play area point 4Z: " + str(AGKVR.Chaperone_GetPlayAreaPoint4Z()) + Chr(10)

	endif


	if dataInput = 6
		myStr = "DEVICE INFO COMMANDS:" + Chr(10) + Chr(10)
		myStr = myStr + "HMD Serial number: " + AGKVR.HMD_GetSerialNumber() + Chr(10)
		//myStr = myStr + "HMD tracking system: " + AGKVR.HMD_GetTrackingSystem() + Chr(10)
		myStr = myStr + "HMD Model number: " + AGKVR.HMD_GetModelNumber() + Chr(10)
		myStr = myStr + "HMD Manufacturer: " + AGKVR.HMD_GetManufacturer() + Chr(10)
		myStr = myStr + "Right Controller serial number: " + AGKVR.RCntrl_GetSerialNumber() + Chr(10)
		//myStr = myStr + "Right Controller tracking system: " + AGKVR.RCntrl_GetTrackingSystem() + Chr(10)
		myStr = myStr + "Right Controller model number: " + AGKVR.RCntrl_GetModelNumber() + Chr(10)
		myStr = myStr + "Right Controller Manufacturer: " + AGKVR.RCntrl_GetManufacturer() + Chr(10)
		myStr = myStr + "Left Controller serial number: " + AGKVR.LCntrl_GetSerialNumber() + Chr(10)
		//myStr = myStr + "Left Controller tracking system: " + AGKVR.LCntrl_GetTrackingSystem() + Chr(10)
		myStr = myStr + "Left Controller model number: " + AGKVR.LCntrl_GetModelNumber() + Chr(10)
		myStr = myStr + "Left Controller Manufacturer: " + AGKVR.LCntrl_GetManufacturer() + Chr(10)

	endif

SetTextString( myText, myStr )

/*===============================================================================
	   RENDER 2D
	===============================================================================*/

SetTextVisible( myText, 1 )
	SetRenderToImage(screen2DImg,0)
	SetClearColor( 255, 255, 255 )                  // Setting the clear / background colour for the 2D render
	ClearScreen()                                   // Clear the render image before rendering
	Update2D( GetFrameTime() )
	Render2DFront()
	setrendertoscreen()
	SetTextVisible( myText, 0 )
	setObjectImage(screen2D,screen2DImg,0)

/*===============================================================================
	   RENDER TO VR
	===============================================================================*/

AGKVR.UpdatePlayer( )

//This command renders to the HMD.
	AGKVR.Render(  )

/*===============================================================================
	   RENDER TO SCREEN
	===============================================================================*/

SetCameraPosition( 1, 0.0, 1.80, 0.0)
	SetCameraLookAt(1, getObjectX(screen2D), getObjectY(screen2D), getObjectZ(screen2D), 0.0)

Sync()

loop

function trueFalse (meNumber as Integer)
	reply as String
	if meNumber = 0
		reply = "NO"
	else
		reply = "YES"
	endif
endfunction reply

function checkmarks (meNumber as Integer)
	reply as String
	if meNumber = 0
		reply = "[  ]   "
	else
		reply = "[V]   "
	endif
endfunction reply

function seatedStanding (meNumber as Integer)
	reply as String
	if meNumber = 0
		reply = "SEATED"
	else
		reply = "STANDING"
	endif
endfunction reply

+ Code Snippet


// Project: HMD data
// Created: 2018-03-21

// show all errors
SetErrorMode(2)

// set window properties
SetWindowTitle( "HMD data" )
SetWindowSize( 1024, 1024, 0 )
SetWindowAllowResize( 1 ) // allow the user to resize the window

// set display properties
SetVirtualResolution( 1024, 1024 ) // doesn't have to match the window
SetAntialiasMode( 1 ) // 1=4xMSAA
SetSyncRate( 90, 0 )
SetScissor( 0,0,0,0 ) // use the maximum available screen space, no black borders
UseNewDefaultFonts( 1 ) // since version 2.0.22 we can use nicer default fonts

//Load the AGKVR plugin
#import_plugin AGKVR


/*===============================================================================
   VR TECH STUFFIE
===============================================================================*/

//Set the Camera Range in AGKVR
//It is necessary to use this command for setting the camera's range instead of the standard AGK SetCameraRange command
//AGKVR.SetCameraRange( 0.01, 1000.0 )
AGKVR.SetCameraRange( 0.01, 1000.0 )

//Initialiaze AGKVR
// The parameters are the Right and Left Eye image ID's that will be used to render to the HMD
InitError As Integer
RightEyeImg As Integer = 500
LeftEyeImg As Integer = 501
InitError = AGKVR.Init( RightEyeImg, LeftEyeImg )
// InitError = 0: SUCCESS!
// InitError = 1: Unable to init VR runtime
// InitError = 2: Compositor initialization failed.

//This command will lock the player's heading direction
//to follow the turn angle of the HMD. This would be common in FPS games, where
//you want the forward moving direction's turn angle to change based on where the
//player is looking. LockPlayerTurn is ON(1) by default
AGKVR.LockPlayerTurn( 1 )

//This command will lock the player's heading direction (forward on the Z axis)
//to follow the pitch angle of the HMD. This would be useful in a freeflight style game
//where you want the forward moving direction's pitch angle to change based on where the
//player is looking. LockPlayerPitch is OFF(0) by default
AGKVR.LockPlayerPitch( 0 )





myStr as String

myText = CreateText(myStr)
SetTextPosition ( myText, 10, 10 )
SetTextSize ( myText, 25 )
SetTextVisible( myText, 0 )
SetTextColor( myText, 0, 0, 0, 255 )
SetTextMaxWidth( myText, 800 )

theFont = LoadFont( "Now-Medium.otf" )
SetTextFont( myText, theFont )


/*===============================================================================
   DISPLAYED TEXT
===============================================================================*/


screen2D = CreateObjectPlane( 1.024, 1.024 )

SetObjectPosition(screen2D, 0.0, 1.8, 0.6)
setObjectRotation (screen2D, 0, 0, 0)

screen2DImg = CreateRenderImage (1600,1600,0,0)

dataInput = 1 // the kind of input displayed at the monitor



do

	// Escape to exit
	if GetRawKeyPressed(27)
		AGKVR.Shutdown()	// Clean shutdown
		End
	endif

	if GetRawKeyPressed(49) then dataInput = 1 // 1 === SETUP COMMANDS:
	if GetRawKeyPressed(50) then dataInput = 2 // 2 === PLAYER COMMANDS:
	if GetRawKeyPressed(51) then dataInput = 3 // 3 === CONTROLLER COMMANDS: (LEFT)
	if GetRawKeyPressed(52) then dataInput = 4 // 4 === CONTROLLER COMMANDS: (RIGHT)
	if GetRawKeyPressed(53) then dataInput = 5 // 5 === CHAPERONE COMMANDS:
	if GetRawKeyPressed(54) then dataInput = 6 // 6 === DEVICE INFO COMMANDS:

	if dataInput = 1
		myStr = "SETUP COMMANDS:" + Chr(10) + Chr(10)
		myStr = myStr + "HMD present: " + trueFalse(AGKVR.IsHmdPresent()) + Chr(10)
		myStr = myStr + "Runtime installed: " + trueFalse(AGKVR.IsRuntimeInstalled()) + Chr(10)
		myStr = myStr + "Tracking space: " + seatedStanding(AGKVR.GetTrackingSpace()) + Chr(10)
		myStr = myStr + "World scale: " + str(AGKVR.GetWorldScale()) + Chr(10)
	endif

	if dataInput = 2
		myStr = "PLAYER COMMANDS:" + Chr(10) + Chr(10)
		myStr = myStr + "Player X position: " + str(AGKVR.GetPlayerX()) + Chr(10)
		myStr = myStr + "Player Y position: " + str(AGKVR.GetPlayerY()) + Chr(10)
		myStr = myStr + "Player Z position: " + str(AGKVR.GetPlayerZ()) + Chr(10)
		myStr = myStr + "Player X angle: " + str(AGKVR.GetPlayerAngleX()) + Chr(10)
		myStr = myStr + "Player Y angle: " + str(AGKVR.GetPlayerAngleY()) + Chr(10)
		myStr = myStr + "Player Z angle: " + str(AGKVR.GetPlayerAngleZ()) + Chr(10)
		myStr = myStr + "HMD X position: " + str(AGKVR.GetHMDX()) + Chr(10)
		myStr = myStr + "HMD Y position: " + str(AGKVR.GetHMDY()) + Chr(10)
		myStr = myStr + "HMD Z position: " + str(AGKVR.GetHMDZ()) + Chr(10)
		myStr = myStr + "HMD X angle: " + str(AGKVR.GetHMDAngleX()) + Chr(10)
		myStr = myStr + "HMD Y angle: " + str(AGKVR.GetHMDAngleY()) + Chr(10)
		myStr = myStr + "HMD Z angle: " + str(AGKVR.GetHMDAngleZ()) + Chr(10)
		myStr = myStr + "Right hand X position: " + str(AGKVR.GetRightHandX()) + Chr(10)
		myStr = myStr + "Right hand Y position: " + str(AGKVR.GetRightHandY()) + Chr(10)
		myStr = myStr + "Right hand Z position: " + str(AGKVR.GetRightHandZ()) + Chr(10)
		myStr = myStr + "Right hand X angle: " + str(AGKVR.GetRightHandAngleX()) + Chr(10)
		myStr = myStr + "Right hand Y angle: " + str(AGKVR.GetRightHandAngleY()) + Chr(10)
		myStr = myStr + "Right hand Z angle: " + str(AGKVR.GetRightHandAngleZ()) + Chr(10)
		myStr = myStr + "Left hand X position: " + str(AGKVR.GetLeftHandX()) + Chr(10)
		myStr = myStr + "Left hand Y position: " + str(AGKVR.GetLeftHandY()) + Chr(10)
		myStr = myStr + "Left hand Z position: " + str(AGKVR.GetLeftHandZ()) + Chr(10)
		myStr = myStr + "Left hand X angle: " + str(AGKVR.GetLeftHandAngleX()) + Chr(10)
		myStr = myStr + "Left hand Y angle: " + str(AGKVR.GetLeftHandAngleY()) + Chr(10)
		myStr = myStr + "Left hand Z angle: " + str(AGKVR.GetLeftHandAngleZ()) + Chr(10)
	endif


	if dataInput = 3
		myStr = "CONTROLLER COMMANDS:: (LEFT)" + Chr(10) + Chr(10)
		myStr = myStr + "Left controller found: " + trueFalse(AGKVR.LeftControllerFound()) + Chr(10)
		myStr = myStr + "Left controller X axis: " + str(AGKVR.LeftController_JoyX()) + Chr(10)
		myStr = myStr + "Left controller Y axis: " + str(AGKVR.LeftController_JoyY()) + Chr(10)
		myStr = myStr + "Left controller trigger: " + str(AGKVR.LeftController_Trigger()) + Chr(10)
		myStr = myStr + "Left controller grib: " + trueFalse(AGKVR.LeftController_Grip()) + Chr(10) // is it really an integer?	Yes.
		myStr = myStr + "Left controller button 1: " + trueFalse(AGKVR.LeftController_Button1()) + Chr(10)
		myStr = myStr + "Left controller button 2: " + trueFalse(AGKVR.LeftController_Button2()) + Chr(10)
		myStr = myStr + "Left controller finger pointed: " + trueFalse(AGKVR.LeftController_GetFingerPointed()) + Chr(10)
		myStr = myStr + "Left controller thumbs up: " + trueFalse(AGKVR.LeftController_GetThumbUp()) + Chr(10) //
		myStr = myStr + "Left controller Axis trigger X [0]: " + str(AGKVR.LeftController_AxisTriggerX(0)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger X [1]: " + str(AGKVR.LeftController_AxisTriggerX(1)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger X [2]: " + str(AGKVR.LeftController_AxisTriggerX(2)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger X [3]: " + str(AGKVR.LeftController_AxisTriggerX(3)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger X [4]: " + str(AGKVR.LeftController_AxisTriggerX(4)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger X [5]: " + str(AGKVR.LeftController_AxisTriggerX(5)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger Y [0]: " + str(AGKVR.LeftController_AxisTriggerY(0)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger Y [1]: " + str(AGKVR.LeftController_AxisTriggerY(1)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger Y [2]: " + str(AGKVR.LeftController_AxisTriggerY(2)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger Y [3]: " + str(AGKVR.LeftController_AxisTriggerY(3)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger Y [4]: " + str(AGKVR.LeftController_AxisTriggerY(4)) + Chr(10)
		myStr = myStr + "Left controller Axis trigger Y [5]: " + str(AGKVR.LeftController_AxisTriggerY(5)) + Chr(10)
		myStr = myStr + "buttons:" + Chr(10)
		for allB = 0 to 63
			myStr = myStr + str(allB) + ":" + checkmarks(AGKVR.LeftController_ButtonPressed(allB))
		next
	endif

	if dataInput = 4
		myStr = "CONTROLLER COMMANDS:: (RIGHT)" + Chr(10) + Chr(10)
		myStr = myStr + "Right controller found: " + trueFalse(AGKVR.RightControllerFound()) + Chr(10)
		myStr = myStr + "Right controller X axis: " + str(AGKVR.RightController_JoyX()) + Chr(10)
		myStr = myStr + "Right controller Y axis: " + str(AGKVR.RightController_JoyY()) + Chr(10)
		myStr = myStr + "Right controller trigger: " + str(AGKVR.RightController_Trigger()) + Chr(10)
		myStr = myStr + "Right controller grib: " + trueFalse(AGKVR.RightController_Grip()) + Chr(10) // is it really an integer? Yes.
		myStr = myStr + "Right controller button 1: " + trueFalse(AGKVR.RightController_Button1()) + Chr(10)
		myStr = myStr + "Right controller button 2: " + trueFalse(AGKVR.RightController_Button2()) + Chr(10)
		myStr = myStr + "Right controller finger pointed: " + trueFalse(AGKVR.RightController_GetFingerPointed()) + Chr(10)

		myStr = myStr + "Right controller thumbs up: " + trueFalse(AGKVR.RightController_GetThumbUp()) + Chr(10)
		myStr = myStr + "Right controller Axis trigger X [0]: " + str(AGKVR.RightController_AxisTriggerX(0)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger X [1]: " + str(AGKVR.RightController_AxisTriggerX(1)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger X [2]: " + str(AGKVR.RightController_AxisTriggerX(2)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger X [3]: " + str(AGKVR.RightController_AxisTriggerX(3)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger X [4]: " + str(AGKVR.RightController_AxisTriggerX(4)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger X [5]: " + str(AGKVR.RightController_AxisTriggerX(5)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger Y [0]: " + str(AGKVR.RightController_AxisTriggerY(0)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger Y [1]: " + str(AGKVR.RightController_AxisTriggerY(1)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger Y [2]: " + str(AGKVR.RightController_AxisTriggerY(2)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger Y [3]: " + str(AGKVR.RightController_AxisTriggerY(3)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger Y [4]: " + str(AGKVR.RightController_AxisTriggerY(4)) + Chr(10)
		myStr = myStr + "Right controller Axis trigger Y [5]: " + str(AGKVR.RightController_AxisTriggerY(5)) + Chr(10)
		myStr = myStr + "buttons:" + Chr(10)
		for allB = 0 to 63
			myStr = myStr + str(allB) + ":" + checkmarks(AGKVR.RightController_ButtonPressed(allB))
		next
	endif



	if dataInput = 5
		myStr = "CHAPERONE COMMANDS:" + Chr(10) + Chr(10)
		myStr = myStr + "Play area size X: " + str(AGKVR.Chaperone_GetPlayAreaSizeX()) + Chr(10)
		myStr = myStr + "Play area size Z: " + str(AGKVR.Chaperone_GetPlayAreaSizeZ()) + Chr(10)
		myStr = myStr + "Are bounds visible: " + trueFalse(AGKVR.Chaperone_AreBoundsVisible()) + Chr(10)
		myStr = myStr + "play area point 1X: " + str(AGKVR.Chaperone_GetPlayAreaPoint1X()) + Chr(10)
		myStr = myStr + "play area point 1Y: " + str(AGKVR.Chaperone_GetPlayAreaPoint1Y()) + Chr(10)
		myStr = myStr + "play area point 1Z: " + str(AGKVR.Chaperone_GetPlayAreaPoint1Z()) + Chr(10)
		myStr = myStr + "play area point 2X: " + str(AGKVR.Chaperone_GetPlayAreaPoint2X()) + Chr(10)
		myStr = myStr + "play area point 2Y: " + str(AGKVR.Chaperone_GetPlayAreaPoint2Y()) + Chr(10)
		myStr = myStr + "play area point 2Z: " + str(AGKVR.Chaperone_GetPlayAreaPoint2Z()) + Chr(10)
		myStr = myStr + "play area point 3X: " + str(AGKVR.Chaperone_GetPlayAreaPoint3X()) + Chr(10)
		myStr = myStr + "play area point 3Y: " + str(AGKVR.Chaperone_GetPlayAreaPoint3Y()) + Chr(10)
		myStr = myStr + "play area point 3Z: " + str(AGKVR.Chaperone_GetPlayAreaPoint3Z()) + Chr(10)
		myStr = myStr + "play area point 4X: " + str(AGKVR.Chaperone_GetPlayAreaPoint4X()) + Chr(10)
		myStr = myStr + "play area point 4Y: " + str(AGKVR.Chaperone_GetPlayAreaPoint4Y()) + Chr(10)
		myStr = myStr + "play area point 4Z: " + str(AGKVR.Chaperone_GetPlayAreaPoint4Z()) + Chr(10)

	endif


	if dataInput = 6
		myStr = "DEVICE INFO COMMANDS:" + Chr(10) + Chr(10)
		myStr = myStr + "HMD Serial number: " + AGKVR.HMD_GetSerialNumber() + Chr(10)
		//myStr = myStr + "HMD tracking system: " + AGKVR.HMD_GetTrackingSystem() + Chr(10)
		myStr = myStr + "HMD Model number: " + AGKVR.HMD_GetModelNumber() + Chr(10)
		myStr = myStr + "HMD Manufacturer: " + AGKVR.HMD_GetManufacturer() + Chr(10)
		myStr = myStr + "Right Controller serial number: " + AGKVR.RCntrl_GetSerialNumber() + Chr(10)
		//myStr = myStr + "Right Controller tracking system: " + AGKVR.RCntrl_GetTrackingSystem() + Chr(10)
		myStr = myStr + "Right Controller model number: " + AGKVR.RCntrl_GetModelNumber() + Chr(10)
		myStr = myStr + "Right Controller Manufacturer: " + AGKVR.RCntrl_GetManufacturer() + Chr(10)
		myStr = myStr + "Left Controller serial number: " + AGKVR.LCntrl_GetSerialNumber() + Chr(10)
		//myStr = myStr + "Left Controller tracking system: " + AGKVR.LCntrl_GetTrackingSystem() + Chr(10)
		myStr = myStr + "Left Controller model number: " + AGKVR.LCntrl_GetModelNumber() + Chr(10)
		myStr = myStr + "Left Controller Manufacturer: " + AGKVR.LCntrl_GetManufacturer() + Chr(10)

	endif



	SetTextString( myText, myStr )


	/*===============================================================================
	   RENDER 2D
	===============================================================================*/

	SetTextVisible( myText, 1 )
	SetRenderToImage(screen2DImg,0)
	SetClearColor( 255, 255, 255 )                  // Setting the clear / background colour for the 2D render
	ClearScreen()                                   // Clear the render image before rendering
	Update2D( GetFrameTime() )
	Render2DFront()
	setrendertoscreen()
	SetTextVisible( myText, 0 )
	setObjectImage(screen2D,screen2DImg,0)

	/*===============================================================================
	   RENDER TO VR
	===============================================================================*/

	AGKVR.UpdatePlayer( )

	//This command renders to the HMD.
	AGKVR.Render(  )


	/*===============================================================================
	   RENDER TO SCREEN
	===============================================================================*/

	SetCameraPosition( 1, 0.0, 1.80, 0.0)
	SetCameraLookAt(1, getObjectX(screen2D), getObjectY(screen2D), getObjectZ(screen2D), 0.0)


    Sync()

loop



function trueFalse (meNumber as Integer)
	reply as String
	if meNumber = 0
		reply = "NO"
	else
		reply = "YES"
	endif
endfunction reply

function checkmarks (meNumber as Integer)
	reply as String
	if meNumber = 0
		reply = "[  ]   "
	else
		reply = "[V]   "
	endif
endfunction reply


function seatedStanding (meNumber as Integer)
	reply as String
	if meNumber = 0
		reply = "SEATED"
	else
		reply = "STANDING"
	endif
endfunction reply

To use my program remember to click on its window to make it active, so it accepts keyboard input. Use the number keys to change what information is displayed:
1 :: Setup Commands
2 :: Player Commands
3 :: Controller Commands (Left)
4 :: Controller Commands (Right)
5 :: Chaperone commands
6 :: Device Info commands

Using the program above I got the following info for the Oculus Rift CV1. (I have no VIVE, so I can't test that. If anyone has VIVE and could check how it worked, it would be super helpful!)

LEFT TOUCH CONTROLLER:
---------------------------------------------------------------------------------------------

float AGKVR.LeftController_JoyX() // Left Touch Controller: Thumbstick X axis (-1.0 to +1.0)
float AGKVR.LeftController_JoyY() // Left Touch Controller: Thumbstick Y axis (-1.0 to +1.0)
float AGKVR.LeftController_Trigger() // Left Touch Controller: Trigger (0.0 to 1.0)
integer AGKVR.LeftController_Grip() // Left Touch Controller: Grip
integer AGKVR.LeftController_Button1() // Left Touch Controller: Button Y
integer AGKVR.LeftController_Button2() // Left Touch Controller: Button X or Thumbstick click
integer AGKVR.LeftController_GetFingerPointed() // Left Touch Controller: Not touching trigger
integer AGKVR.LeftController_GetThumbUp() // Left Touch Controller: Not touching Button Y, Button X or the thumbstick
float AGKVR.LeftController_AxisTriggerX(0) // Left Touch Controller: Thumbstick X axis (-1.0 to +1.0)
float AGKVR.LeftController_AxisTriggerX(1) // Left Touch Controller: Trigger (0.0 to 1.0)
float AGKVR.LeftController_AxisTriggerX(2) // Left Touch Controller: Grip (0.0 to 1.0)
float AGKVR.LeftController_AxisTriggerY(0) // Left Touch Controller: Thumbstick Y axis (-1.0 to +1.0)
integer AGKVR.LeftController_ButtonPressed(1) // Left Touch Controller: Button Y
integer AGKVR.LeftController_ButtonPressed(2) // Left Touch Controller: Grip
integer AGKVR.LeftController_ButtonPressed(7) // Left Touch Controller: Button X
integer AGKVR.LeftController_ButtonPressed(32) // Left Touch Controller: Thumbstick Click
integer AGKVR.LeftController_ButtonPressed(33) // Left Touch Controller: Trigger
integer AGKVR.LeftController_ButtonPressed(34) // Left Touch Controller: Grip

RIGHT TOUCH CONTROLLER:
---------------------------------------------------------------------------------------------

float AGKVR.RightController_JoyX() // Right Touch Controller: Thumbstick X axis (-1.0 to +1.0)
float AGKVR.RightController_JoyY() // Right Touch Controller: Thumbstick Y axis (-1.0 to +1.0)
float AGKVR.RightController_Trigger() // Right Touch Controller: Trigger (0.0 to 1.0)
integer AGKVR.RightController_Grip() // Right Touch Controller: Grip
integer AGKVR.RightController_Button1() // Right Touch Controller: Button B
integer AGKVR.RightController_Button2() // Right Touch Controller: Button A or Thumbstick click
integer AGKVR.RightController_GetFingerPointed() // Right Touch Controller: Not touching trigger
integer AGKVR.RightController_GetThumbUp() // Right Touch Controller: Not touching Button A, Button B or the thumbstick
float AGKVR.RightController_AxisTriggerX(0) // Right Touch Controller: Thumbstick X axis (-1.0 to +1.0)
float AGKVR.RightController_AxisTriggerX(1) // Right Touch Controller: Trigger (0.0 to 1.0)
float AGKVR.RightController_AxisTriggerX(2) // Right Touch Controller: Grip (0.0 to 1.0)
float AGKVR.RightController_AxisTriggerY(0) // Right Touch Controller: Thumbstick Y axis (-1.0 to +1.0)
integer AGKVR.RightController_ButtonPressed(1) // Right Touch Controller: Button B
integer AGKVR.RightController_ButtonPressed(2) // Right Touch Controller: Grip
integer AGKVR.RightController_ButtonPressed(7) // Right Touch Controller: Button A
integer AGKVR.RightController_ButtonPressed(32) // Right Touch Controller: Thumbstick Click
integer AGKVR.RightController_ButtonPressed(33) // Right Touch Controller: Trigger
integer AGKVR.RightController_ButtonPressed(34) // Right Touch Controller: Grip

DEVICE INFO:
---------------------------------------------------------------------------------------------

string AGKVR.HMD_GetModelNumber() // "Oculus Rift CV1"
string AGKVR.HMD_GetManufacturer() // "Oculus"
string AGKVR.RCntrl_GetModelNumber() // "Oculus Rift CV1 (Right Controller)"
string AGKVR.RCntrl_GetManufacturer() // "Oculus"
string AGKVR.LCntrl_GetModelNumber() // "Oculus Rift CV1 (Left Controller)"
string AGKVR.LCntrl_GetManufacturer() // "Oculus"

BTW, the following commands didn't work, so I skipped them:
AGKVR.HMD_GetTrackingSystem()
AGKVR.RCntrl_GetTrackingSystem()
AGKVR.LCntrl_GetTrackingSystem()
... Also, I noticed that the AGKVR documentation is missing AGKVR.Shutdown()

Back to top

Profile PM

Ortu

DBPro Master

16

Years of Service

User Offline

Joined: 21st Nov 2007

Location: Austin, TX

Posted: 21st Mar 2018 23:33

Link

Looks like some great info, wish i had an oculus to use it!

http://games.joshkirklin.com/sulium

A single player RPG featuring a branching, player driven storyline of meaningful choices and multiple endings alongside challenging active combat and intelligent AI.

Back to top

Profile PM Email Website

xCept

21

Years of Service

User Offline

Joined: 15th Dec 2002

Location:

Posted: 22nd Mar 2018 00:30

Link

This is very useful thank you! I have yet to even test the VR functionality despite owning a Rift and buying the plugin it on launch day but will keep this reference handy.

Back to top

Profile PM Email Website

Santman

12

Years of Service

User Offline

Joined: 15th Sep 2011

Location: Inverness

Posted: 22nd Mar 2018 11:24

Link

VR worked fine for me, then suddenly stopped working, says the licence is no longer valid. Not quite sure what happened, but I had to remove it all. Worked well before that though.

Back to top

Profile PM

basicFanatic

6

Years of Service

User Offline

Joined: 7th Jun 2017

Location:

Posted: 25th Mar 2018 19:24

Link

Having just gotten my Leap Motion thingie recently, I decided to opt-in to the Leap Motion newsletter. Got it in my mailbox yesterday and it just happens to mention AppGameKit!

Attachments

Login to view attachments

Back to top

Profile PM

basicFanatic

6

Years of Service

User Offline

Joined: 7th Jun 2017

Location:

Posted: 28th Mar 2018 14:19 Edited at: 28th Mar 2018 21:44

Link

Since AppGameKit only has a single camera, the VR plugin recycles the main camera to render for both eyes. I have long had a suspicion that this caused the normal camera to misbehave. Now I have proof! In the code below, the plane should logically be placed exactly at the center of the screen. Yet it is offset slightly upwards and to the right. Comment away the VR code, and the plane hits center:

// Project: test-position
// Created: 2018-03-28

// show all errors
SetErrorMode(2)

//Init App
SetWindowTitle( "test-position" )
SetSyncRate(90, 0)
SetWindowSize( 540, 600, 0 )
UseNewDefaultFonts( 1 )
SetClearColor( 128, 128, 128 )

//Load the AppGameKitVR plugin
#import_plugin AGKVR

/***************************************************
  Initialiaze AGKVR
***************************************************/

// The parameters are the Right and Left Eye image ID's that will be used to render to the HMD
InitError As Integer
RightEyeImg As Integer = 500
LeftEyeImg As Integer = 501
InitError = AGKVR.Init( RightEyeImg, LeftEyeImg )
// InitError = 0: SUCCESS!
// InitError = 1: Unable to init VR runtime
// InitError = 2: Compositor initialization failed.

//Set the Camera Range in AGKVR
//It is necessary to use this command for setting the camera's range instead of the standard AGK SetCameraRange command
AGKVR.SetCameraRange( 0.01, 1000.0 )

/***************************************************
  ADD THE CANVAS
***************************************************/

canvasPlane = CreateObjectPlane ( 1.08, 1.20 )
SetObjectColor ( canvasPlane, 255, 0, 0, 0 )
SetObjectPosition (canvasPlane, 0.0, 0.0, 0.0)
SetObjectRotation (canvasPlane, 0.0, 0.0, 0.0)
SetObjectLightMode ( canvasPlane, 0 )

/***************************************************
  PLACE THE CAMERA
***************************************************/

SetCameraPosition( 1,  GetObjectX(canvasPlane), GetObjectY(canvasPlane), GetObjectZ(canvasPlane)-1.0)
SetCameraRotation( 1, 0.0, 0.0, 0.0 )
setCameraRange( 1, 0.01, 1000.0)

do

AGKVR.UpdatePlayer()
	AGKVR.Render()

Sync()

loop

+ Code Snippet


// Project: test-position
// Created: 2018-03-28

// show all errors
SetErrorMode(2)

//Init App
SetWindowTitle( "test-position" )
SetSyncRate(90, 0)
SetWindowSize( 540, 600, 0 )
UseNewDefaultFonts( 1 )
SetClearColor( 128, 128, 128 )


//Load the AppGameKitVR plugin
#import_plugin AGKVR



/***************************************************
  Initialiaze AGKVR
***************************************************/

// The parameters are the Right and Left Eye image ID's that will be used to render to the HMD
InitError As Integer
RightEyeImg As Integer = 500
LeftEyeImg As Integer = 501
InitError = AGKVR.Init( RightEyeImg, LeftEyeImg )
// InitError = 0: SUCCESS!
// InitError = 1: Unable to init VR runtime
// InitError = 2: Compositor initialization failed.

//Set the Camera Range in AGKVR
//It is necessary to use this command for setting the camera's range instead of the standard AGK SetCameraRange command
AGKVR.SetCameraRange( 0.01, 1000.0 )



/***************************************************
  ADD THE CANVAS
***************************************************/

canvasPlane = CreateObjectPlane ( 1.08, 1.20 )
SetObjectColor ( canvasPlane, 255, 0, 0, 0 )
SetObjectPosition (canvasPlane, 0.0, 0.0, 0.0)
SetObjectRotation (canvasPlane, 0.0, 0.0, 0.0)
SetObjectLightMode ( canvasPlane, 0 )


/***************************************************
  PLACE THE CAMERA
***************************************************/

SetCameraPosition( 1,  GetObjectX(canvasPlane), GetObjectY(canvasPlane), GetObjectZ(canvasPlane)-1.0)
SetCameraRotation( 1, 0.0, 0.0, 0.0 )
setCameraRange( 1, 0.01, 1000.0)

do

    AGKVR.UpdatePlayer()
	AGKVR.Render()



    Sync()

loop

Also, it looks like the VR forces the camera to use its aspect ratio (The Oculus Rift uses two pairs of 1080:1200 screens)

EDIT: I said 1080:1200 was the aspect ratio forced upon the camera, but my experimentation shows something closer to 1080:1290

Back to top

Profile PM

basicFanatic

6

Years of Service

User Offline

Joined: 7th Jun 2017

Location:

Posted: 5th Apr 2018 22:51

Link

Further nitpicking:

AGKVR saves renders each eye as a seperate image:

+ Code Snippet

RightEyeImg As Integer = 500
LeftEyeImg As Integer = 501

I got the clever idea of saving one of those images to the harddrive:

+ Code Snippet

// Press I to save a screenie in the doc folder
if GetRawKeyPressed( 73 ) then SaveImage( RightEyeImg, "raw:" + GetDocumentsPath () + "\abc_453th.png" )

This saved me an image with the size of 1330 x 1584 pixels. This is strange, since the oculus should have 1080 x 1200 pixels for either eye. But it sorta fits the aspect ratio I had guessed at myself.

Damn ... I miss Ron!

Back to top

Profile PM

Sorry your browser is not supported!

AppGameKit Classic Chat / VR :: The ultimate guide to Oculus input stuff!

Attachments
