uniform sampler2D texture0; // Base
uniform sampler2D texture1; // Green Color
uniform sampler2D texture2; // Slope
uniform sampler2D texture3;  //not used
uniform sampler2D texture4; // SplatMap
uniform sampler2D texture5; //not used
uniform sampler2D texture7; // Shadow

varying highp vec3 posVarying;
varying mediump vec3 normalVarying;
varying mediump vec2 uvVarying;
varying mediump vec2 uv4Varying;
varying mediump vec3 lightVarying;

mediump vec3 GetPSLighting( mediump vec3 normal, highp vec3 pos );
mediump vec3 ApplyFog( mediump vec3 color, highp vec3 pointPos );
mediump vec4 blend(mediump vec4 TextureA, float a1, mediump vec4 TextureB, float a2);

void main()
{

	float slope = 1.0-normalVarying.y;
	float slopeblend = clamp( (slope/.5)*1.6, 0.0, 1.0 );

	mediump vec4 splatMap = texture2D(texture4, uv4Varying);
	mediump vec4 basetex = texture2D(texture0, uvVarying);
	mediump vec4 greentex = texture2D(texture1, uvVarying);
	mediump vec4 slopetex= texture2D(texture2, uvVarying);
	// Base Color
	mediump vec4 finalColor = redtex;

	if ( splatMap.g > 0.001 )
	{
		finalColor = blend(greentex, splatMap.g, basetex , (1.0-splatMap.g));
	}


	if (posVarying.y < -.65)
	{

		finalColor = mix( finalColor, vec4(0.1098, .6627, .7882, 1.0), clamp(abs((posVarying.y+.65)/(2.5-.65)), 0.0, 1.0 ) );
		gl_FragColor = finalColor;
	}
	else
	{


		if ( slopeblend > .01 )
		{
			slopeblend = slopeblend-.01;
			finalColor = blend( finalColor, (1.0-slopeblend) ,slopetex, slopeblend );
		}


		mediump vec3 light = lightVarying + GetPSLighting( normalVarying, posVarying );

		finalColor.rgb = ApplyFog( finalColor.rgb * light, posVarying );

		gl_FragColor = finalColor;

	}
}



mediump vec4 blend(mediump vec4 TextureA, float a1, mediump vec4 TextureB, float a2)
{
    float depth = 0.2;
    float ma = max(TextureA.a + a1, TextureB.a + a2) - depth;

    float b1 = max(TextureA.a + a1 - ma, 0);
    float b2 = max(TextureB.a + a2 - ma, 0);

    return (TextureA.rgba * b1 + TextureB.rgba * b2) / (b1 + b2);
}

#version 120
uniform sampler2D texture0;
uniform sampler2D texture1;
uniform sampler2D texture2;
varying highp vec3 posVarying;
varying mediump vec3 normalVarying;
varying highp vec2 uvVarying;
varying highp vec2 uv1Varying;
varying mediump vec3 lightVarying;

varying mediump vec3 TangentViewPos;
varying mediump vec3 TangentLightPos;
varying mediump vec3 TangentFragPos;

uniform vec2 agk_resolution;

mediump vec3 GetPSLighting( mediump vec3 normal, highp vec3 pos );
mediump vec3 ApplyFog( mediump vec3 color, highp vec3 pointPos );
mediump vec4 blend(mediump vec4 TextureA, float a1, mediump vec4 TextureB, float a2);
mediump vec2 ParallaxMapping( mediump vec2 uvCoord, vec3 viewDir, mediump sampler2D heightMap );

lowp float tx = 0.0;
lowp float ty = 0.0;

mediump vec4 splatMap;
mediump vec4 Color;
mediump vec3 normalMap;
mediump vec3 ambient;
mediump vec3 halfwayDir;
mediump vec3 specular;
mediump vec2 texCoords0;

void main()
{

	float diff;
	float spec;
	vec2 newuv;
	vec3 viewDir  = normalize( TangentViewPos - TangentFragPos );
    viewDir = normalize(viewDir);
	vec3 lightDir = normalize( TangentLightPos - TangentFragPos );
	lightDir = normalize(lightDir);

	float slope = 1.0-normalVarying.y;
	float slopeblend = clamp( (slope/.5)*1.7, 0.0, 1.0 );

	//texCoords0 = ParallaxMapping( uvVarying, viewDir, texture2 );
	//Color =  texture2D(texture2, texCoords0);


	ty = 0.0; //1st row
	splatMap = texture2D(texture0, uvVarying);

	if (splatMap.g > 0.001) {
		tx = 0.0; //first column
		newuv.x = tx + (fract(uv1Varying.x * 4.0) * 0.25);
		newuv.y = ty + (fract(uv1Varying.y * 4.0) * 0.25);
		texCoords0 = ParallaxMapping( newuv, viewDir, texture1 );
		if(texCoords0.x > .2499) texCoords0.x = .2499;
		if(texCoords0.y > .2499) texCoords0.y = .2499;
		if(texCoords0.x < .0001) texCoords0.x = .0001;
		if(texCoords0.y < .0001) texCoords0.y = .0001;
		mediump vec4 greenColor = texture2D(texture1, texCoords0);
		newuv.y = .25 + (fract(newuv.y * 4.0) * 0.25);
		texCoords0 = ParallaxMapping( newuv, viewDir, texture1 );
		if(texCoords0.x > .2499) texCoords0.x = .2499;
		if(texCoords0.y > .4999) texCoords0.y = .4999;
		if(texCoords0.x < .0001) texCoords0.x = .0001;
		if(texCoords0.y < .2501) texCoords0.y = .2501;
		ambient = 0.1 * greenColor.rgb;
		normalMap = texture2D(texture1, texCoords0).rgb;
		normalMap = normalize(normalMap*2.0-1.0);
		diff = max(dot(lightDir, normalMap), 0.0);
		greenColor = diff*greenColor;
		//spec
		halfwayDir = normalize(lightDir + viewDir);
		spec = pow(max(dot(normalMap, halfwayDir), 0.0), 32.0);
		specular = vec3(0.2) * spec;
		greenColor = greenColor+vec4(specular,1.0)+vec4(ambient,1.0);
		Color = blend(Color,(1.0-splatMap.g), greenColor,splatMap.g);
	}
	if (splatMap.r > 0.001) {
		tx = 0.25; //second column
		newuv.x = tx + (fract(uv1Varying.x * 4.0) * 0.25);
		newuv.y = ty + (fract(uv1Varying.y * 4.0) * 0.25);
		texCoords0 = ParallaxMapping( newuv, viewDir, texture1 );
		if(texCoords0.x > .4999) texCoords0.x = .4999;
		if(texCoords0.y > .2499) texCoords0.y = .2499;
		if(texCoords0.x < .2501) texCoords0.x = .2501;
		if(texCoords0.y < .0001) texCoords0.y = .0001;
		mediump vec4 redColor = texture2D(texture1, texCoords0);
		newuv.y = .25 + (fract(newuv.y * 4.0) * 0.25);
		texCoords0 = ParallaxMapping( newuv, viewDir, texture1 );
		if(texCoords0.x > .4999) texCoords0.x = .4999;
		if(texCoords0.y > .4999) texCoords0.y = .4999;
		if(texCoords0.x < .2501) texCoords0.x = .2501;
		if(texCoords0.y < .2501) texCoords0.y = .2501;
		ambient = 0.25 * redColor.rgb;
		normalMap = texture2D(texture1, texCoords0).rgb;
		normalMap = normalize(normalMap*2.0-1.0);
		diff = max(dot(lightDir, normalMap), 0.0);
		redColor = diff*redColor;
		//spec
		halfwayDir = normalize(lightDir + viewDir);
		spec = pow(max(dot(normalMap, halfwayDir), 0.0), 32.0);
		specular = vec3(0.2) * spec;
		redColor = redColor+vec4(specular,1.0)+vec4(ambient,1.0);
		Color = blend(Color,(1.0-splatMap.r), redColor,splatMap.r);
	}
	if (splatMap.b > 0.0001) {
		tx = 0.5; //3rd column
		newuv.x = tx + (fract(uv1Varying.x * 4.0) * 0.25);
		newuv.y = ty + (fract(uv1Varying.y * 4.0) * 0.25);
		texCoords0 = ParallaxMapping( newuv, viewDir, texture1 );
		if(texCoords0.x > .7499) texCoords0.x = .7499;
		if(texCoords0.y > .2499) texCoords0.y = .2499;
		if(texCoords0.x < .5001) texCoords0.x = .5001;
		if(texCoords0.y < .0001) texCoords0.y = .0001;
		mediump vec4 blueColor = texture2D(texture1, texCoords0);
		newuv.y = .25 + (fract(newuv.y * 4.0) * 0.25);
		texCoords0 = ParallaxMapping( newuv, viewDir, texture1 );
		if(texCoords0.x > .74999) texCoords0.x = .74999;
		if(texCoords0.y > .4999) texCoords0.y = .4999;
		if(texCoords0.x < .5001) texCoords0.x = .5001;
		if(texCoords0.y < .2501) texCoords0.y = .2501;
		ambient = 0.1 * blueColor.rgb;
		normalMap = texture2D(texture1, texCoords0).rgb;
		normalMap = normalize(normalMap*2.0-1.0);
		diff = max(dot(lightDir, normalMap), 0.0);
		blueColor = diff*blueColor;
		//spec
		halfwayDir = normalize(lightDir + viewDir);
		spec = pow(max(dot(normalMap, halfwayDir), 0.0), 32.0);
		specular = vec3(0.2) * spec;
		blueColor = blueColor+vec4(specular,1.0)+vec4(ambient,1.0);
		Color = blend(Color,(1.0-splatMap.b), blueColor,splatMap.b);
	}

	if (slopeblend > .0001) {
		tx = 0.75;
		newuv.x = tx + (fract(uv1Varying.x * 4.0) * 0.25);
		newuv.y = ty + (fract(uv1Varying.y * 4.0) * 0.25);
		texCoords0 = ParallaxMapping( newuv, viewDir, texture1 );
		if(texCoords0.x > .9999) texCoords0.x = .9999;
		if(texCoords0.y > .2499) texCoords0.y = .2499;
		if(texCoords0.x < .7501) texCoords0.x = .7501;
		if(texCoords0.y < .0001) texCoords0.y = .0001;
		mediump vec4 steepColor = texture2D(texture1, texCoords0);
		newuv.y = .25 + (fract(newuv.y * 4.0) * 0.25);
		texCoords0 = ParallaxMapping( newuv, viewDir, texture1 );
		if(texCoords0.x > .9999) texCoords0.x = .9999;
		if(texCoords0.y > .4999) texCoords0.y = .4999;
		if(texCoords0.x < .7501) texCoords0.x = .7501;
		if(texCoords0.y < .2501) texCoords0.y = .2501;
		ambient = 0.1 * steepColor.rgb;
		normalMap = texture2D(texture1, texCoords0).rgb;
		normalMap = normalize(normalMap*2.0-1.0);
		diff = max(dot(lightDir, normalMap), 0.0);
		steepColor = diff*steepColor;
		//spec
		halfwayDir = normalize(lightDir + viewDir);
		spec = pow(max(dot(normalMap, halfwayDir), 0.0), 32.0);
		specular = vec3(0.2) * spec;
		steepColor = steepColor+vec4(specular,1.0)+vec4(ambient,1.0);
		Color = blend(Color,(1.0-slopeblend), steepColor,slopeblend);
	}

	if (posVarying.y < -.65)
	{
		Color = mix( Color, vec4(0.1098, .6627, .7882, 1.0), clamp(abs((posVarying.y+.65))/1.0, 0.0, 1.0 ) );
	}

	mediump vec3 norm = normalize(normalVarying);
	mediump vec3 light = lightVarying + GetPSLighting( norm, posVarying );
	Color.rgb = ApplyFog( Color.rgb * light, posVarying );
	// final output
	gl_FragColor = Color;
}

mediump vec4 blend(mediump vec4 TextureA, float a1, mediump vec4 TextureB, float a2)
{
    float depth = 0.2;
    float ma = max(TextureA.a + a1, TextureB.a + a2) - depth;

    float b1 = max(TextureA.a + a1 - ma, 0);
    float b2 = max(TextureB.a + a2 - ma, 0);

    return (TextureA.rgba * b1 + TextureB.rgba * b2) / (b1 + b2);
}

vec2 ParallaxMapping( mediump vec2 texCoords, mediump vec3 viewDir, mediump sampler2D heightMap )
{
    vec2 ScaleBias = vec2(0.02, 0.01);
    float height = texture2D(heightMap, texCoords).a;
    float HSB = height * ScaleBias.x - ScaleBias.y;
    vec2 textOffset = texCoords + (viewDir.xy * HSB)*.25;
    return textOffset;
}

#version 120
attribute highp vec3 position;
attribute mediump vec3 normal;
attribute mediump vec2 uv;

varying highp vec3 posVarying;
varying mediump vec3 TangentViewPos;
varying mediump vec3 TangentLightPos;
varying mediump vec3 TangentFragPos;
varying mediump vec3 normalVarying;
varying highp vec2 uvVarying;
varying highp vec2 uv1Varying;
varying mediump vec3 lightVarying;

mediump vec3 GetVSLighting( mediump vec3 normal, highp vec3 pos );

uniform highp mat3 agk_WorldNormal;
uniform highp mat4 agk_World;
uniform highp mat4 agk_ViewProj;
uniform mediump vec3 agk_CameraPos;

uniform mediump vec4 uvBounds0;
uniform mediump vec4 uvBounds1;
uniform mediump vec4 uvBounds2;
uniform mediump vec4 uvBounds3;
uniform mediump vec4 uvBounds4;
uniform mediump vec4 uvBounds5;

void main()
{
	uvVarying = uv * uvBounds0.xy + uvBounds0.zw;
	uv1Varying = uv * uvBounds1.xy + uvBounds1.zw;
	highp vec4 pos = agk_World * vec4(position,1.0);
	gl_Position = agk_ViewProj * pos;
	mediump vec3 norm = normalize(agk_WorldNormal * normal);
	posVarying = pos.xyz;
	normalVarying = norm;
	lightVarying = GetVSLighting( norm, posVarying );

	mediump vec3 Normal =  normalize(normal*2.0-1.0);

	mediump vec3 tangent;
	if ( length(c1) > length(c2) ) { tangent = c1;  } else { tangent = c2;}
	tangent = normalize(tangent);
    vec3 T = normalize(mat3(agk_World)*tangent);
    vec3 N = normalize(mat3(agk_World)*normal);
    T = normalize(T-dot(T,N)*N);
    mediump vec3 binormal = normalize(cross(N, T));
    vec3 B = normalize(mat3(agk_World)*binormal);
	mediump mat3 TBN = transpose(mat3( T, B, N ));
	TangentViewPos = TBN*agk_CameraPos;
	TangentLightPos = TBN*vec3(20.0,45.0,-75.0);//(agk_CameraPos+vec3(-5.0,40.0,-30.0) );
	TangentFragPos = TBN*posVarying;
}
