select level
		case 0
			s = "$=Y$;Y$<Y$9]..." // Line one from the clipboard
			m = "543,541 "           // Line two from the clipboard
		endcase
		case default
			Message("Invalid level : "+str(level))
		endcase
	endselect

// Project: pmd
// Created: 19-10-29

// show all errors

#option_explicit

SetErrorMode(2)

// set window properties
// set window properties
SetWindowTitle( "Pac me dead" )
//SetImmersiveMode( 1 )
SetOrientationAllowed( 1, 0, 0, 0 ) // allow both portrait and landscape on mobile devices

SetWindowSize( GetDeviceWidth(), GetDeviceHeight(), 0 )
SetWindowAllowResize( 1 ) // allow the user to resize the window
SetPrintSize(10)

// set display properties
SetVirtualResolution( GetWindowWidth()/2, GetWindowHeight()/2 ) // doesn't have to match the window

//SetSyncRate( 30, 0 ) // 30fps instead of 60 to save battery
SetVSync(1)
SetScissor( 0,0,0,0 ) // use the maximum available screen space, no black borders
UseNewDefaultFonts( 1 )

SetDefaultMagFilter(0)
SetDefaultMinFilter(0)

#constant	TRUE			1
#constant	FALSE			0

#constant	SHIFT_PALETTE	35
#constant	SHIFT_LENGTH		48

#constant	TILE_FEAST		29
#constant	TILE_SNACK		30
#constant	TILE_PAC		25
#constant	TILE_STAR		33
#constant	TILE_END		28

#constant	GRID_FREE		0
#constant	GRID_WALL		1
#constant	GRID_FEAST		50
#constant	GRID_SNACK		5
#constant	GRID_END		4
#constant	GRID_STAR		100

#constant	NOT_FLIPPED		0
#constant	FLIP_HORIZ		1
#constant	FLIP_VERT		2

#constant	KEY_LEFT        37
#constant	KEY_UP          38
#constant	KEY_RIGHT       39
#constant	KEY_DOWN        40

#constant	PAC_STILL		0
#constant	PAC_MOVE		1

#constant	PAC_CHEW		0
#constant	PAC_GOBBLE		1

#constant	MODE_TITLE		0
#constant	MODE_PLAY		1
#constant	MODE_SUCCESS		2
#constant	MODE_DEAD		3
#constant	MODE_INTRO		4

//SetPhysicsDebugOn()

SetDefaultMagFilter(0)
SetDefaultMinFilter(0)

type tPos2d
	x		as integer
	y		as integer
endtype

type tPosf
	x		as float
	y		as float
endtype

type tTile
	typ		as integer
	angle	as integer
	flip	as integer
	id		as integer
	name	as string
endtype

type	 tPac
	id		as integer
	eat		as integer
	move	as integer
	dir		as tPos2d
	target	as tPos2d
	star	as integer
	win		as integer
	finish	as integer
	time	as integer
	shoot	as tPosf
	trail	as integer
	last	as tPos2D
	trails	as integer[]
	eaten	as tPos2d[]
	moves	as tPos2d[]
endtype

type	 tGrid
	typ		as integer
	id		as integer
	done	as integer
endtype

type	 tScore
	text	as integer
	amount	as integer
endtype

type	tConnect
	pos		as tPos2d
	obj		as tTile
	move	as integer
	start	as tPos2D
	target	as tPos2d
	dir		as integer
endtype

type tStars
	id		as integer[]
	starImg	as integer
	slotImg	as integer
	count	as integer
	total	as integer
	slot	as integer
endtype

type tGame
	title	as integer
	score	as tScore
	water	as integer
	stars	as tStars
	mode	as integer
	lastPtr	as tPos2d
	grid	as tGrid[-1, -1]
	camCtr 	as float
	connect	as tConnect[]
endtype

global TILE_MARK		as integer
global TILE_EXIT		as integer
global TILE_TITLE	as integer

pacMan				as tPac
game				as tGame

game.mode = MODE_INTRO

tiles				as tTile[]
sprites		 		as tTile[]

//CompressImage("sheet.png")
//end

sheet	as integer

sheet = GenerateImage()

CreateWater(game, sheet)

SetupText(game, pacMan)

Loadsprites(game, sheet, pacMan, sprites)

tiles =LoadLevel(game, 0, pacMan, sprites)

repeat
	select game.mode
		case MODE_SUCCESS
			Camera(game, pacMan)
			MovePacMan(game, pacMan, sprites)
			DrawTitles(game, "You da Pacman", pacMan)
			SetSpriteAngle(pacMan.id, GetSpriteAngle(pacMan.id) + 5)
		endcase
		case MODE_DEAD
			DrawTitles(game, "You got Paced", pacMan)
			MoveWater(game, pacMan, tiles)
			MovePacMan(game, pacMan, sprites)
			SetSpriteAngle(pacMan.id, GetSpriteAngle(pacMan.id) + 5)
			SetSpriteX(pacMan.id, GetSpriteX(pacMan.id) + pacMan.shoot.x)
			SetSpriteY(pacMan.id, GetSpriteY(pacMan.id) + pacMan.shoot.y)
			pacMan.shoot.x = pacMan.shoot.x * .95
			pacMan.shoot.y = pacMan.shoot.y * .95
			inc pacMan.shoot.y
			if	GetSpriteXByOffset(pacMan.id) > GetViewOffsetX() + GetVirtualWidth() or	GetSpriteXByOffset(pacMan.id) < GetViewOffsetX()
				pacMan.shoot.x = -pacMan.shoot.x
			endif
		endcase
		case default
			Input(game, pacMan)
			Control(game, pacMan)
			MovePacMan(game, pacMan, sprites)
			CheckConnections(game, pacMan)
			Camera(game, pacMan)
			MoveWater(game, pacMan, tiles)
		endcase
	endselect
//	print("("+str(GetDeviceWidth())+","+str(GetDeviceHeight())+")")
//	DumpGrid(game)
	UpdateAllTweens(GetFrameTime())
    Sync()
until GetRawKeyPressed(27)

end

function	DrawTitles(game ref as tGame, s as string, pac ref as tPac)
	x	as float
	y	as float
	i	as integer

	inc pac.time

	if pac.time > 30
		SetTextString(pac.finish, s)
		if GetTextVisible(pac.finish) = 1
			pac.time = 15
			SetTextVisible(pac.finish, 0)
		else
			FixSpriteToScreen(game.title, 1)
			SetSpriteColorAlpha(game.title, 0xff)
			SetSpritePosition(game.title, GetVirtualWidth()/2 - GetSpriteWidth(game.title)/2, 0)
			SetTextVisible(pac.finish, 1)
			pac.time = 0
		endif

		SetTextPosition(pac.finish, GetVirtualWidth()/2, GetSpriteHeight(game.title))
		SetTextPosition(game.score.text, GetVirtualWidth()/2 - GetTextTotalWidth(game.score.text)/2, GetTextY(pac.finish)+GetTextTotalHeight(pac.finish)*1.2)
		x = (GetVirtualWidth()/2) - ((game.stars.total+1)*16)/2
		y = GetTextY(pac.finish)+GetTextTotalHeight(pac.finish)*1.2+GetTextTotalHeight(game.score.text)*1.2
		for i=0 to game.stars.total
			SetSpritePosition(game.stars.id[i], x + i * 16, y)
		next
	endif
endfunction

function	MoveWater(game ref as tGame, pac ref as tPac, tiles ref as tTile[])
	f	as tPosf
	t	as tPosf
	y	as integer

	if game.mode = MODE_PLAY
		SetSpritePosition(game.water, GetViewOffsetX(), GetSpriteY(game.water) - 0.5)
	else
		SetSpritePosition(game.water, GetViewOffsetX(), GetSpriteY(game.water))
	endif

	f.x = WorldToScreenX(GetViewOffsetX())
	f.y = WorldToScreenY(GetSpriteY(game.water)+GetSpriteHeight(game.water)-1)
	t.x = GetVirtualWidth()
	t.y = GetVirtualHeight()
	DrawBox(f.x, f.y, t.x, t.y, 0xffff00ff,  0xffff00ff, 0xffff00ff, 0xffff00ff, 1)


	y = WorldToScreenY(GetSpriteY(pac.id))

	if ( GetSpriteY(game.water) + 16 < GetSpriteY(pac.id) ) or ( game.mode = MODE_DEAD and y > GetVirtualHeight() * .7)
		if y > GetVirtualHeight()
			pac = pac
		endif
		pac.shoot.x = random(0, 10) - 5
		pac.shoot.y = random(10, 20) * -1
		if game.mode <> MODE_DEAD
			StopSprite(pac.id)
			PlaySprite(pac.id, 8, 1, 1, 3)
			DimLevel(game, pac, tiles)
		endif
		game.mode = MODE_DEAD
	endif
endfunction

function SetupText(game ref as tGame, pac ref as tPac)
	f as integer

	if pac.finish = 0
		game.score.text = CreateText("Score : 0")
		if GetFileExists("FFFFORWA.TTF")
			f = LoadFont("FFFFORWA.TTF")
			SetTextFont(game.score.text, f)
		endif
		SetTextSize(game.score.text, GetDeviceHeight() / 37)
		FixTextToScreen(game.score.text, 1)
		SetTextColor(game.score.text, 0xff, 0xff, 00, 0xff)
		pac.finish = CreateText("")
		SetTextAlignment( pac.finish, 1 )
		SetTextFont(pac.finish, f)
		SetTextSize(pac.finish, GetDeviceHeight() / 15)
		FixTextToScreen(pac.finish, 1)
		SetTextColor(pac.finish, 0xff, 0xff, 00, 0xff)
	endif

	SetTextPosition(game.score.text, 0, 0)
	SetTextVisible(pac.finish, 0)

endfunction


function	DimLevel(game ref as tGame, pac ref as tPac, tiles ref as tTile[])
	i	as integer
	t	as tTile

	SetSpriteColorAlpha(game.title, 0x20)

	for i=0 to tiles.length
		t = tiles[i]
		SetSpriteColorAlpha(t.id, 0x20)
	next

	SetSpriteColorAlpha(pac.id, 0xff)

endfunction

function	Camera(game ref as tGame, pac ref as tPac)
	target	as tPosf
	pos		as tPosf
	stp		as tPosf
	ease	as float = .1

	if game.mode = MODE_INTRO
		ease = 0.01
	else
		ease = 0.05
	endif

	if game.mode <> MODE_INTRO and game.mode <> MODE_TITLE
		if game.camCtr > 0.5
			dec game.camCtr, 0.001
		endif
		target.x = GetSpriteXByOffset(pac.id) - GetVirtualWidth() * game.camCtr
	else
		game.camCtr = 0.7
		target.x = GetSpriteXByOffset(pac.id) - GetVirtualWidth() * game.camCtr
	endif

	target.y = GetSpriteYByOffset(pac.id) - GetVirtualHeight() * 0.7

	pos.x = GetViewOffsetX()
	pos.y = GetViewOffsetY()

	SetViewOffset(pos.x + (target.x - pos.x) * ease, pos.y + (target.y - pos.y) * ease)

	if game.mode = MODE_INTRO and abs(target.x - pos.x) < 40
		game.mode = MODE_TITLE
	endif

endfunction

function	DumpGrid(game ref as tGame)
	s 	as string
	y	as integer
	x	as integer
	v	as integer

	for y = 0 to game.grid.length
		for x = 0 to game.grid[y].length
			v = game.grid[y, x].typ
			if v < 10
				printc(v)
			else
				printc("x")
			endif

		next
		print("")
	next

endfunction

function	MovePacMan(game ref as tGame, pac ref as tPac, sprites ref as tTile[])
	pos	as tPos2d
	g	as tPos2d
	null	as tPos2d
	i	as integer
	t	as integer

	for i=0 to pac.trails.length
		t = pac.trails[i]
		if GetSpritePlaying(t) = 0
			DeleteSprite(t)
			pac.trails.remove(i)
			dec i
		endif
	next

	if ( pac.dir.x = 0 and pac.dir.y = 0 ) or game.mode = MODE_DEAD
		exitfunction
	endif

	SetSpritePosition(pac.id, GetSpriteX(pac.id) + pac.dir.x * 16, GetSpriteY(pac.id) + pac.dir.y * 16)

	pos.x = GetSpriteX(pac.id)
	pos.y = GetSpriteY(pac.id)

	if pac.last.x <> pos.x or pac.last.y <> pos.y
		t = CloneSprite(pac.trail)
		SetSpritePosition(t, pac.last.x, pac.last.y)
		SetSpriteAngle(t, GetSpriteAngle(pac.id))
		SetSpriteFlip(t, GetSpriteFlippedH(pac.id),  GetSpriteFlippedV(pac.id))
		PlaySprite(t, 20, 0)
		SetSpriteVisible(t, 1)
		pac.trails.insert(t)
	endif

	pac.last = pos

	g.x = pos.x / 16
	g.y = pos.y / 16

	t = game.grid[g.y, g.x].typ

	select t
		case GRID_FEAST, GRID_SNACK, GRID_STAR
			if game.grid[g.y, g.x].done = 0
				game.score.amount = game.score.amount + game.grid[g.y, g.x].typ
				SetTextString(game.score.text, "Score : "+str(game.score.amount))
				game.grid[g.y, g.x].done = 1
				if t = GRID_STAR
					SetSpriteImage(game.stars.id[game.stars.count], GetSpriteImageID(sprites[TILE_STAR].id))
					dec game.stars.count
				endif
			endif
			SetSpriteVisible(game.grid[g.y, g.x].id, 0)
			pac.eaten.insert(g)
			if pac.eat = PAC_CHEW
				PlaySprite(pac.id, 8, 1, 1, 3)
				pac.eat = PAC_GOBBLE
			endif
		endcase
		case GRID_END
			game.mode = MODE_SUCCESS
			SetSpriteVisible(game.grid[g.y, g.x].id, 0)
			PlaySprite(pac.id, 8, 1, 1, 5)
			g.x = g.x
			WinPac(pac)
		endcase
		case default
			if pac.eat = PAC_GOBBLE
				PlaySprite(pac.id, 8, 1, 4, 5)
				pac.eat = PAC_CHEW
			endif
		endcase
	endselect

	if pos.x = pac.target.x and pos.y = pac.target.y
		pac.dir = null
		pac.move = PAC_STILL
		for i=0 to pac.eaten.length
			g = pac.eaten[i]
			game.grid[g.y, g.x].typ = GRID_FREE
		next
	endif

endfunction

function	CheckConnections(game ref as tGame, pac ref as tPac)
	i	as integer
	c	as tConnect

	for i=0 to game.connect.length
		c = game.connect[i]
		if c.move = FALSE
			if GetSpriteX(pac.id) = c.pos.x and GetSpriteY(pac.id) = c.pos.y
				c.move = TRUE
				FindTarget(game, c)
			endif
		else
			MoveObject(game, c, pac)
		endif
		game.connect[i] = c
	next

endfunction

function	MoveObject(game ref as tGame, c ref as tConnect, pac ref as tPac)
	p		as tPos2d

	p.x = GetSpriteX(c.obj.id) + ( 4 * c.dir )
	p.y = GetSpriteY(c.obj.id)

	SetSpritePosition(c.obj.id, p.x, p.y)

	if ( p.x = c.target.x and p.y = c.target.y ) or ( p.x = c.start.x and p.y = c.start.y )
		c.dir = -c.dir
		SetSpriteFlip(c.obj.id, abs(GetSpriteFlippedH(c.obj.id)-1), GetSpriteFlippedV(c.obj.id))
	endif

	if GetSpriteCollision(pac.id, c.obj.id)
		game.mode = MODE_DEAD
		sync()
		sleep(200)
	endif

endfunction

function	FindTarget(game ref as tGame, c ref as tConnect)
	dir		as integer
	g		as tPos2d

	c.start.x = GetSpriteX(c.obj.id)
	c.start.y = GetSpriteY(c.obj.id)

	g.x = c.start.x / 16
	g.y = c.start.y / 16

	c.target.y = g.y

	if GetSpriteFlippedH(c.obj.id)
		dir = 1
		c.target.x = 0
	else
		dir = -1
		c.target.x = game.grid[c.target.y].length
	endif

	while game.grid[c.target.y, c.target.x].typ = GRID_FREE
		c.target.x = c.target.x + dir
	endwhile

	c.target.x = c.target.x + -dir

	c.target.x = c.target.x * 16
	c.target.y = c.target.y * 16
	c.dir = -dir
endfunction

function	Input(game ref as tGame, pac ref as tPac)
	dir	as tPos2d
	p	as tPos2d
	n	as string

	n = GetDeviceBaseName()
	if n = "linux" or n = "mac" or n = "windows"
		dir.x = GetRawKeyPressed(KEY_RIGHT) - GetRawKeyPressed(KEY_LEFT)
		dir.y = GetRawKeyPressed(KEY_DOWN) - GetRawKeyPressed(KEY_UP)
		if dir.x <> 0 or dir.y <> 0
			pac.moves.insert(dir)
		endif
	else
		if GetPointerPressed()
			game.lastPtr.x = GetPointerX()
			game.lastPtr.y = GetPointery()
		endif

		if GetPointerReleased()
			p.x = GetPointerX() - game.lastPtr.x
			p.y = GetPointery() - game.lastPtr.y
			if abs(p.x) > abs(p.y)
				dir.x = p.x / abs(p.x)
			else
				dir.y = p.y / abs(p.y)
			endif
			pac.moves.insert(dir)
		endif
	endif

	if pac.moves.length > -1
		game.mode = MODE_PLAY
	endif

endfunction

function	Control(game ref as tGame, pac ref as tPac)
	dir	as tPos2d
	pos	as tPos2d
	g	as integer
	d	as integer

	if game.mode = MODE_INTRO
		exitfunction
	endif

	if pac.move = PAC_MOVE
		exitfunction
	endif

	if pac.moves.length < 0
		exitfunction
	endif

	dir = pac.moves[pac.moves.length]
	pac.moves.remove(pac.moves.length)

	if dir.y = 0 and dir.x = 0
		exitfunction
	endif

	pac.last.x = -1
	pac.last.y = -1

	if dir.x <> 0 and dir.y <> 0
		dir.y = 0
	endif

	pos.x = GetSpriteX(pac.id) / 16
	pos.y = GetSpriteY(pac.id) / 16

	d = 0

	if dir.x <> 0
		g = pos.x + dir.x
		repeat
			if game.grid[pos.y, g].typ = GRID_WALL
				exit
			endif
			g = g + dir.x
			inc d
		until g < 0 or g > game.grid[pos.y].length

		if d = 0
			exitfunction
		endif

		g = g + dir.x * -1

		if game.grid[pos.y + 1, pos.x].typ = GRID_WALL
			if dir.x < 0
				SetSpriteFlip(pac.id, 1, 0)
				SetSpriteAngle(pac.id, 0)
			else
				SetSpriteFlip(pac.id, 0, 0)
				SetSpriteAngle(pac.id, 0)
			endif
		else
			if dir.x < 0
				SetSpriteFlip(pac.id, 1, 1)
				SetSpriteAngle(pac.id, 0)
			else
				SetSpriteFlip(pac.id, 0, 1)
				SetSpriteAngle(pac.id, 0)
			endif
		endif

		pos.x = g * 16
		pos.y = pos.y * 16
	endif

	if dir.y <> 0
		g = pos.y + dir.y
		repeat
			if game.grid[g, pos.x].typ = GRID_WALL
				exit
			endif
			inc d
			g = g + dir.y
		until g < 0 or g > game.grid.length

		if d = 0
			exitfunction
		endif

		if game.grid[pos.y, pos.x + 1].typ = GRID_WALL
			if dir.y < 0
				SetSpriteFlip(pac.id, 0, 0)
				SetSpriteAngle(pac.id, -90)
			else
				SetSpriteFlip(pac.id, 1, 0)
				SetSpriteAngle(pac.id, -90)
			endif
		else
			if dir.y < 0
				SetSpriteFlip(pac.id, 1, 0)
				SetSpriteAngle(pac.id, 90)
			else
				SetSpriteFlip(pac.id, 0, 0)
				SetSpriteAngle(pac.id, 90)
			endif
		endif

		g = g + dir.y * -1

		pos.x = pos.x * 16
		pos.y = g * 16
	endif

	pac.dir = dir
	pac.target = pos

	pac.move = PAC_MOVE
	pac.eat = PAC_CHEW

	PlaySprite(pac.id, 8, 1, 4, 5)
endfunction

function GenerateImage()
	meta as string = "sheet.png 160 288 -16777216 -1 -16711681 -2200807 -65281 -3223858 -6513508 -10263709"
	data as string = "#~V$8#U%7#7%7#7%7#w$:#S%3&1%3#5%3&1%3#5%3&1%3#v$;#4$8#C%4&1%4#3%4&1%4#3%4&1%4#t$5#1$1#1$#3$:#5$8#3%;#3%;#3%;#5%7#7%7#V$5#1$1#1$#3$;#3$:#2%2#<%2#<%2#=%3&1%3#5%3&1%3#U$5#1$1#1$#2$5#1$1#1$#3$;#1%2#<%2#<%2#<%4&1%4#3%2#%&1%4#T$5#1$1#1$#2$5#1$1#1$#2$<#1%2#1'#9%2'1#:%2#3'#7%2#%7#3%3#%6#T$<#2$5#1$1#1$#2$5#1$1#1$#1%2#'2#1'#5%2'4#7%2#2'2#6%3#;%3#\$4#1$#1$#$#2$<#2$5#1$1#1$#1%3'#'2#6%3'5#5%3#'1#1'#5%3#;%3#%6#T$4#1$#1$#$#2$4#1$#1$#$#2$<#1%4#1'#7%4#:%4'#9%2#%7#4%1#%6#U$4#6$#2$4#1$#1$#$#2$3#2$#1$#$#1%6#8%6#8%6#9%9#6%7#V$4#6$#2$4#6$1#1$3#2$#1$#$#1%;#3%;#3%;#5%7#f$4#6$#$6#6$2#$3#7$#2%9#5%9#5%9#s$7#4$:#4$9#5$1#3%7#7%7#7%7#s$>#1$>#$>#~Q$#$;#3$<#2$<#u&1#1&1#~{&1#1&1#~{&1#1&1#~{&1#1&1#w'1#5'1#w&1#1&1#Z(3#G'2#5'2#:&m#1&@#;&3#:()3(#D&1'2#5'2&1#8&m#1&A#9&5#8()*3)(#:)1#6&1'2#5'2&1#6&1#~1&1#9&1#1&1#8()*3)(#9)*1)#7'2#5'2#8&1#~1&1#9&1#1&1#8()*3)(#9)*1)#7'2#5'2#6&1#3&[#1&=#1&A#9&5#8()*3)(#:)1#6&1'2#5'2&1#4&1#3&[#1&=#1&@#;&3#:()3(#D&1'2#5'2&1#4&1#1&1#D'?#4&1#1&1#9&1#1&1#Z(3#G'2#5'2#6&1#1&1#E'3#'3#'3#5&1#1&1#9&1#1&1#w'1#5'1#7&1#1&1#E'3#'3#'3#5&1#1&1#9&1#1&1#~;&1#1&1#F'1#2'1#2'1#6&1#1&1#9&1#1&1#~;&1#1&1#F'1#2'1#2'1#6&1#1&1#9&1#1&1#~~~~~~~~P'#6'#5'#~p'2#4'2#3'2#~n'2#6'2#1'2#~n'2#8'5#~i'#3'2#:'3#~i'2#1'2#;'3#~j'5#;'5#Y'5#;%#{'3#;'2#1'2#W'7#;%#?%#j'1#;'2#3'2#F'7#5';#:%1#>%#x'#5'#C'O#3%1#2%2#8%#3%1#~5'#='P#%1#1%1#2%2#4%#2%1#1%2#9%#2%#s'3#7'S#1%1#%3#%3#4%1#%2#1%2#4%#2%1#1%2#8%1#1%1#:%#2%#R'_#?%?#6(1#Z'1#'1#'1#z%1#6%?#5(#1(#;%6#3%=#~9%1#6%?#5(#1(#:%8#2%#;%#3'9#y%1#6%?#4(1#1(1#8%9#2%#%9#%#2';#w%3#5%?#4(#3(#8%2#2%3#2%#%#7%#%#'#';#'#u%3#5%?(5#3(5#3%2#2%3#2%#%#%5#%#%#'#';#'#p%=#%?(#=(#2%3#2%3#2%#%#%#3%#%#%#2';#s%;#1%?(1#;(1#%5#1%4#2%#%#%#3%#%#%#'#'1#2'1#2'1#'#s%7#3%?#(2#7(2#1%;#3%#%#%#3%#%#%#'#'2#'3#'2#'#t%5#4%?#2(#7(#3%:#4%#%#%#3%#%#%#2';#v%6#3%?#2(#7(#4%4#9%#%#%5#%#%#'#'2#5'2#'#s%7#3%?#2(#7(1#4%3#9%#%#7%#%#'#';#'#s%2#1%3#2%?#1(1#8(#5%3#8%#%9#%#2';#t%2#4%1#2%?#1(#2(4#1(1#4%3#8%#;%#3'9#u%#7%1#1%?#1(#(2#2(1#1(#5%1#9%=#~B%?#1(2#5(3#T'1#'1#'1#~~~~~=(#7(#7(#~m('(#5('(#5('(#~k('2(#3('2(#3('2(#~i*'*'*'*#1*'*'*'*#1*'*'*'*#~~~h(N#~a(2'('('('('('('('('('('('('('(2#~_(1'N(1#~^('P(#~^('P(#~\(#'R#(#~Y('#('P(#'(#~W('1#'R#'1(#~U('*'#'R#'*'(#~U*'*#'3#1'F#1'3#*'*#~W*'#'3#3'B#3'3#'*#~Y*#'3#5'>#5'3#*#~\'4#6':#6'4#~^'4#1*#5'6#5*#1'4#~\(#'4#1(#$#5'2#5$#(#1'4#(#~Y('#'4#1(#6'4#6(#1'4#'(#~W('1#'4#1(1#1*1#1'4#1*1#1(1#1'4#'1(#~U('*'#'4(#1(3#1'6#1(3#1('4#'*'(#~U*'*#'5#6('6(#6'5#*'*#~W*'#'5(1#3('8(#3(1'5#'*#~Y*#'7(3':(3'7#*#~\'R#~^'5#F'5#~\(#'5#2(4#(4#(4#2'5#(#~Y('#'6#2(2#2(2#2(2#2'6#'(#~W('1#'6#3(#4(#4(#3'6#'1(#~U('*'#'6#6(#4(#6'6#'*'(#~U*'*#'7#4(2#2(2#4'7#*'*#~W*'#*'6#3(4#(4#3'6*#'*#~Y*#'7(#@('7#*#~\*'7(@'7*#~^*'P*#~^*1'N*1#~_*2'*'*'*'*'*'*'*'*'*'*'*'*'*'*2#~a*N#~~~i*6#1*6#1*6#~i'*'*'#3'*'*'#3'*'*'#~k'2#5'2#5'2#~m'#7'#7'#~~~~~~~~~~~~~~~F%I#~g%I#~g%I#~d%O#k%>#d%9&5%?#k%>#d%9&5%?#g%F#^%;&5%B#d%F#^%;&5%B#b%J#E%5#@%;&5%B#b%J#E%5#@%T#`%L#A%=#<%T#`%L#A%=#:%V#`%N#=%?#:%?#D%1#`%N#=%?#:%:#z%;#8%;#;%C#8%:#z%;#8%;#;%C#8%:#z%;#8%;#;%C#8%:#z%;#8%;#;%C#8%:#z%;#8%;#9%G#6%:#z%;#8%;#9%G#6%:#1'5#p%;#:%;#7%I#6%:#'7#o%;#:%;#7%I#6%:'9#j%?#8%;#9%;#1%;#6%:':#i%?#8%;#9%;#1%;#6%:':#g%C#4%=#7%;#3%;#6%:'3#3'4#8'1#Z%C#4%=#7%;#3%;#6%:'2#5'4#4'1#'1#Z%T#9%;#3%M'#8'3#3'1#^%T#9%;#3%M#:'8#^%R#9%;#3%O#:'7#_%R#9%;#3%O#;'4#a%P#;%_#<'2#b%P#;%_#='1#b%J#?%a#r%J#?%d#D%1#\%?#D%m#9%5#\%?#D%}#^%=#B%~1#^%=#B%|#a%=#A%X#6%M#a%=#A%X#6%M#c%>#>%H#1%=#9%G#f%>#>%H#1%=#9%G#f%>#>%>#=%=#~8%>#>%>#=%=#~8%>#>%<#?%=#~8%>#?%;#?%=#~8%>#?%9#A%=#~8%>#?%9#A%=#~:%9#D%5#E%;#~:%9#D%5#E%;#~<%5#b%;#~<%5#b%;#~~~~~~~~~~~~~e%7#A%3#G%;#~?%7#A%3#G%;#~?%9#=%9#A%A#~;%9#=%9#A%A#~9%;#;%=#=%F#~6%;#;%=#=%F#~6%;#;%=#;%J#~4%;#;%=#;%J#~4%=#7%?#;%J#~4%=#7%?#;%J#~4%=#7%?#9%L#~4%=#7%?#9%L#~2%?#5%A#9%;#7%8#~2%?#5%A#9%;#7%8#~2%?#5%A#9%9#~E%?#5%A#9%9#~E%A#1%C#7%I#~7%A#1%C#7%I#~7%A#1%C#7%L#~4%A#1%C#7%L#~4%W#5%N#~4%W#5%N#~2%Y#3%P#~2%Y#3%P#~2%Y#1%O#~5%Y#1%O#~5%Y#1%O#~5%Y#1%O#~5%7#3%M#1%G#~=%7#3%M#1%G#~=%7#3%?#1%;#1%?#;%8#~%7#3%?#1%;#1%?#;%8#~%7#5%;#3%;#7%9#5%@#|%7#5%;#3%;#7%9#5%@#y%:#E%;#7%R#w%:#E%;#7%R#w%:#E%=#5%R#w%:#E%=#5%R#w%8#G%=#5%P#y%8#G%=#5%P#y%8#G%=#5%N#{%8#G%=#5%N#{%6#I%=#7%J#}%6#I%=#7%J#~R%9#;%C#~W%9#;%C#~q%9#~w%9#~~~~~~~~~~~~~6%=#N%9#~J%=#N%9#~H%A#H%C#~B%A#H%C#~@%E#D%G#G%5#N%=#A%E#D%G#G%5#N%=#?%I#@%I#C%;#J%C#;%I#@%I#C%;#J%C#;%K#>%K#?%?#F%G#9%K#>%K#?%?#F%G#9%;#1%=#<%K#?%C#D%G#9%;#1%=#<%K#?%C#D%G#9%9#5%=#:%;#7%7#?%C#B%K#7%9#5%=#:%;#7%7#?%C#B%K#7%9#5%=#:%;#M%E#B%;#1%?#5%9#5%=#:%;#M%E#B%;#1%?#3%;#7%=#8%G#?%I#@%9#5%=#3%;#7%=#8%G#?%I#@%9#5%=#3%;#7%=#6%K#=%;#1%;#@%9#5%=#3%;#7%=#6%K#=%;#1%;#@%9#5%=#3%9#9%=#6%K#;%;#3%;#@%9#7%=#1%9#9%=#6%K#;%;#3%;#@%9#7%=#1%9#9%=#1%P#;%;#3%V#7%=#1%9#9%=#1%P#;%;#3%V#7%=#1%9#9%`#9%;#1%Z#7%=#1%9#9%`#9%;#1%Z#7%=#1%9#9%^#;%h#7%=#1%9#9%^#;%h#7%=#1%9#9%Z#=%j#9%;#1%9#9%Z#=%j#9%;#3%7#7%R#9%7#3%l#7%=#3%7#7%R#9%7#3%l#7%=#3%7#5%A#6%;#3%p#3%9#7%=#3%7#5%A#6%;#3%p#3%9#7%=#1%;#1%A#8%w#<%7#9%=#1%;#1%A#8%w#<%7#9%_#8%g#1%=#<%7#7%a#8%g#1%=#<%7#7%_#:%[#=%?#8%;#1%c#:%[#=%?#8%;#1%a#>%M#1%9#?%=#6%Q#1%M#>%M#1%9#?%=#6%Q#3%I#@%I#5%7#A%=#6%O#5%I#@%I#5%7#A%=#6%O#7%E#D%C#9%5#C%=#6%O#7%E#D%C#9%5#C%=#6%O#9%?#L%9#[%;#8%K#;%?#L%9#[%;#8%K#?%9#~8%7#<%E#C%9#~8%7#<%E#~m%A#~o%A#~s%9#~w%9#~~~~~~~~~~S"
	array 	as integer[]
	palette	as integer[]
	p		as integer
	i		as integer
	l		as integer
	b		as integer
	mb		as integer

	array.insert(val(GetStringToken(meta, " ", 2)))
	array.insert(val(GetStringToken(meta, " ", 3)))
	array.insert(32)

	for i=4 to CountStringTokens(meta, " ")
		palette.insert(val(GetStringToken(meta, " ", i)))
	next

	for i=1 to len(data)
		l = asc(mid(data,i, 1))
		if l < SHIFT_LENGTH
			p =  palette[l-SHIFT_PALETTE]
			array.insert(p)
		else
			dec l, SHIFT_LENGTH
			for b=1 to l
				array.insert(p)
			next
		endif
	next

	mb = CreateMemblock((array.length + 1) * 4)

	for b=0 to array.length
		SetMemblockInt(mb, b*4, array[b])
	next

	i = CreateImageFromMemblock(mb)

	//SaveImage(i, "sheet.png")
		//DeleteImage(i)
	DeleteMemblock(mb)

	SetImageTransparentColor( i, 0, 0, 0 )

endfunction i

type rle_type
	width	as integer
	height	as integer
	palette	as integer[]
	pixels	as string
endtype

function	CompressImage(name as string)
	mb 		as integer
	image	as integer
	rle		as rle_type
	pixel	as integer
	i		as integer
	p		as integer
	last	as integer
	count	as integer
	s		as string
	f		as integer

	image = LoadImage(name)
	mb = CreateMemblockFromImage(image)

	rle.width = GetMemblockInt(mb, 0)
	rle.height = GetMemblockInt(mb, 4)

	last = 0
	count = 0

	for i=12 to GetMemblockSize(mb)-1 step 4
		pixel = GetMemblockInt(mb, i)
		if last <> pixel
			if count > 0
				rle.pixels = rle.pixels + chr(SHIFT_LENGTH+count)
			endif
			p = LookupPalette(rle.palette, pixel)
			rle.pixels = rle.pixels + chr(SHIFT_PALETTE+p)
			last = pixel
			count=0
		else
			inc count
			if count = 126-SHIFT_LENGTH
				rle.pixels = rle.pixels + chr(SHIFT_LENGTH+count)
				count=0
			endif
		endif
	next

	if count > 0
		rle.pixels = rle.pixels + chr(48+count)
	endif

	f = OpenToWrite(GetStringToken(name,".", 1)+".agc")

	WriteLine(f, "")

	s = 'meta as string = "'+name+" "+str(rle.width)+" "+str(rle.height)
	for i=0 to rle.palette.length
		s = s + " " + str(rle.palette[i])
	next
	s = s + '"'

	WriteLine(f, s)

	s = 'data as string = "'+rle.pixels+'"'

	WriteLine(f, s)
	CloseFile(f)

	DeleteMemblock(mb)

endfunction

function	LookupPalette(p ref as integer[], pixel as integer)
	i as integer

	for i=0 to p.length
		if p[i] = pixel
			exit
		endif
	next

	if i > p.length
		p.insert(pixel)
		i = p.length
	endif

endfunction i

function	Loadsprites(game ref as tGame, sheet as integer, pac ref as tPac, sprites ref as tTile[])
	sprite	as tTile
	i		as integer
	t		as integer
	r		as integer
	blank	as tTile
	w1		as integer
	w2		as integer
	w3		as integer
	img		as integer
	ghost	as integer

	r = 0

// Ghost animation
	ghost = CreateSprite(CopyImage(sheet, 7*16, 0, 3*16, 16))
	SetSpriteAnimation( ghost, 16, 16, 3 )
	PlaySprite(ghost, 10, 1, 1, 3)
	SetSpriteDepth(ghost, 10)
	SetSpriteShapeCircle(ghost, 0, 0, GetSpriteHeight(ghost)/2)

// Walls
	for i=0 to 6
		sprite = blank
		sprite.name = "Wall"
		sprite.id = CreateSprite(CopyImage(sheet, i*16, 16, 16, 16))
		SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
		sprite.typ = i
		FixSpriteToScreen(sprite.id, 1)
		sprites.insert(sprite)
		inc r
	next

// Corners
	for i=1 to 3
		sprite = sprites[0]
		sprite.name = "Corner"
		sprite.id = CloneSprite(sprite.id)
		sprite.angle = i * 90
		sprite.typ = sprites.length + 1
		SetSpriteAngle(sprite.id, sprite.angle)
		SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
		FixSpriteToScreen(sprite.id, 1)
		sprites.insert(sprite)
		inc r
	next

// Horiz Wall
	sprite = sprites[1]
	sprite.name = "Horiz wall"
	sprite.id = CloneSprite(sprite.id)
	sprite.angle = 90
	sprite.typ = sprites.length + 1
	SetSpriteAngle(sprite.id, sprite.angle)
	SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
	FixSpriteToScreen(sprite.id, 1)
	sprites.insert(sprite)
	inc r

// Spikey walls
	for i=1 to 3
		sprite = sprites[2]
		sprite.name = "Spikey wall"
		sprite.id = CloneSprite(sprite.id)
		sprite.angle = i * 90
		sprite.typ = sprites.length + 1
		SetSpriteAngle(sprite.id, sprite.angle)
		SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
		FixSpriteToScreen(sprite.id, 1)
		sprites.insert(sprite)
		inc r
	next

// T Wall
	for i=1 to 3
		sprite = sprites[3]
		sprite.name = "T wall"
		sprite.id = CloneSprite(sprite.id)
		sprite.angle = i * 90
		sprite.typ = sprites.length + 1
		SetSpriteAngle(sprite.id, sprite.angle)
		SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
		FixSpriteToScreen(sprite.id, 1)
		sprites.insert(sprite)
		inc r
	next

// End wall
	for i=1 to 3
		sprite = sprites[5]
		sprite.name = "End wall"
		sprite.id = CloneSprite(sprite.id)
		sprite.angle = i * 90
		sprite.typ = sprites.length + 1
		SetSpriteAngle(sprite.id, sprite.angle)
		SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
		FixSpriteToScreen(sprite.id, 1)
		sprites.insert(sprite)
		inc r
	next

// Shoot wall
	img = CopyImage(sheet, 9*16, 1*16, 16, 16)

	for i=0 to 3
		sprite = sprites[1]
		sprite.name = "Shoot wall"
		sprite.typ = sprites.length + 1
		sprite.id = CreateSprite(img)
		SetSpriteAngle(sprite.id, i*90)
		SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
		FixSpriteToScreen(sprite.id, 1)
		sprites.insert(sprite)
		inc r
	next

// Pac facing right
	sprite = blank
	sprite.name = "Pac right"
	sprite.id = CreateSprite(CopyImage(sheet, 0, 0, 16, 16))
	SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
	sprite.typ = sprites.length + 1
	FixSpriteToScreen(sprite.id, 1)
	sprites.insert(sprite)
	inc r

// Pac facing left
	sprite.id = CloneSprite(sprite.id)
	sprite.name = "Pac left"
	SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
	sprite.typ = sprites.length + 1
	FixSpriteToScreen(sprite.id, 1)
	sprite.flip = FLIP_HORIZ
	SetSpriteFlip(sprite.id, 1, 0)
	sprites.insert(sprite)
	inc r

// Ghost facing right
	sprite = blank
	sprite.name = "Ghost right"
	sprite.id = CloneSprite(ghost)
	SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
	sprite.typ = sprites.length + 1
	FixSpriteToScreen(sprite.id, 1)
	sprites.insert(sprite)
	inc r

// Ghost facing left
	sprite.id = CloneSprite(ghost)
	sprite.name = "Ghost left"
	SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
	sprite.typ = sprites.length + 1
	FixSpriteToScreen(sprite.id, 1)
	sprite.flip = FLIP_HORIZ
	SetSpriteFlip(sprite.id, 1, 0)
	sprites.insert(sprite)
	inc r

// End
	sprite = sprites[1]
	sprite.name = "Game end"
	sprite.typ = sprites.length + 1
	sprite.id = CreateSprite(CopyImage(sheet, 4*16, 3*16, 16, 16))
	SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
	FixSpriteToScreen(sprite.id, 1)
	sprites.insert(sprite)
	inc r

// Food
	for i=7 to 8
		sprite = blank
		sprite.name = "Food"
		sprite.id = CreateSprite(CopyImage(sheet, i*16, 16, 16, 16))
		SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
		sprite.typ = sprites.length + 1
		FixSpriteToScreen(sprite.id, 1)
		sprites.insert(sprite)
		inc r
	next

// Mark
	sprite = sprites[1]
	sprite.name = "Mark"
	sprite.typ = sprites.length + 1
	TILE_MARK = sprite.typ
	sprite.id = CreateSprite(CopyImage(sheet, 5*16, 2*16, 16, 16))
	SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
	FixSpriteToScreen(sprite.id, 1)
	sprites.insert(sprite)
	inc r

// Logo
	sprite = sprites[1]
	sprite.name = "Logo"
	sprite.typ = sprites.length + 1
	TILE_TITLE = sprite.typ
	sprite.id = CreateSprite(CopyImage(sheet, 3*16, 3*16, 16, 16))
	SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
	FixSpriteToScreen(sprite.id, 1)
	sprites.insert(sprite)
	inc r

// Star
	sprite = sprites[1]
	sprite.name = "Star"
	sprite.typ = sprites.length + 1
	pac.star = CopyImage(sheet, 0, 3*16, 16, 16)
	sprite.id = CreateSprite(pac.star)
	SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
	FixSpriteToScreen(sprite.id, 1)
	sprites.insert(sprite)
	inc r

// Thump
	sprite = sprites[1]
	sprite.name = "Thump"
	sprite.typ = sprites.length + 1
	sprite.id = CreateSprite(CopyImage(sheet, 5*16, 3*16, 16, 16))
	SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
	FixSpriteToScreen(sprite.id, 1)
	sprites.insert(sprite)
	inc r

	/*
	sprite = sprites[1]
	sprite.typ = sprites.length + 1
	TILE_CLEAR = sprite.typ
	sprite.id = CreateSprite(CopyImage(sheet, 6*16, 2*16, 16, 16))
	SetSpritePosition(sprite.id, GetVirtualWidth() - GetSpriteWidth(sprite.id), r * GetSpriteHeight(sprite.id))
	FixSpriteToScreen(sprite.id, 1)
	sprites.insert(sprite)
	inc r

	ClearSprite = sprite.id
	*/

	game.stars.slot = CreateSprite(CopyImage(sheet, 2*16, 3*16, 16, 16))
	SetSpritePosition(game.stars.slot, GetVirtualWidth() - GetSpriteWidth(game.stars.slot), r * GetSpriteHeight(game.stars.slot))
	FixSpriteToScreen(game.stars.slot, 1)
	SetSpriteVisible(game.stars.slot, 0)

	game.title = CreateSprite(CopyImage(sheet, 0, 7*16, 160, 176))
	SetSpritePosition(game.title, (GetVirtualWidth() - GetSpriteWidth(game.title)) / 2,
						   (GetVirtualHeight() - GetSpriteHeight(game.title)) / 2)
	FixSpriteToScreen(game.title, 1)

// Pac animation
	pac.id = CreateSprite(CopyImage(sheet, 0, 0, 7*16, 16))
	SetSpriteAnimation( pac.id, 16, 16, 7 )
	PlaySprite(pac.id, 10, 1, 4, 5)
	SetSpriteDepth(pac.id, 10)
	SetSpriteShapeCircle(pac.id, 0, 0, GetSpriteHeight(pac.id)/2)


//Start image
//	pac.star = CopyImage(sheet, 0, 3*16, 16, 16)

// Pac Trail
	pac.trail = CreateSprite(CopyImage(sheet, 0, 2*16, 5*16, 16))
	SetSpriteAnimation( pac.trail, 16, 16, 5)
	SetSpriteDepth(pac.trail, 10)
	SetSpriteVisible(pac.trail, 0)

	for i=0 to sprites.length
		sprite = sprites[i]
		SetSpriteDepth(sprite.id, 5)
	next

	for i=0 to sprites.length
		SetSpriteVisible(sprites[i].id, 0)
	next

endfunction



function	CreateWater(game ref as tGame, sheet as integer)
	w	as integer[]
	id	as integer

	w.insert(createsprite(CopyImage(sheet, 7*16, 2*16, 16, 16)))
	w.insert(createsprite(CopyImage(sheet, 8*16, 2*16, 16, 16)))
	w.insert(createsprite(CopyImage(sheet, 9*16, 2*16, 16, 16)))

	id = CreateWaterImage(w, 0)

	game.water = CreateSprite(id)
	FixSpriteToScreen(game.water, 0)
	SetSpriteDepth(game.water, 15)


	AddSpriteAnimationFrame(game.water,  id)
	AddSpriteAnimationFrame(game.water,  CreateWaterImage(w, 1))
	AddSpriteAnimationFrame(game.water,  CreateWaterImage(w, 2))
	PlaySprite(game.water, 5)

	DeleteSpriteAndImage(w[0])
	DeleteSpriteAndImage(w[1])
	DeleteSpriteAndImage(w[2])

	ClearScreen()

endfunction

function	DeleteSpriteAndImage(id as integer)
	img as integer
	img = GetSpriteImageID(id)
	DeleteSprite(id)
	DeleteImage(img)
endfunction

function	CreateWaterImage(w as integer[], q as integer)
	i 	as integer
	s 	as integer
	e 	as integer
	id	as integer

	SetSpritePosition(w[0], -9999, -9999)
	SetSpritePosition(w[1], -9999, -9999)
	SetSpritePosition(w[2], -9999, -9999)

	ClearScreen()

	for i=0 to GetVirtualWidth() step 16
		e = mod(i, 32)
		select q
			case 0
				if e = 16
					id = w[2]
				else
					id = w[0]
				endif
			endcase
			case 1
				id = w[1]
			endcase
			case 2
				if e = 16
					id = w[0]
				else
					id = w[2]
				endif
			endcase
		endselect
		SetSpritePosition(id, i, 0)
		DrawSprite(id)
	next

	render()

	s = GetImage(0, 0, GetVirtualWidth(), 16)


endfunction s

function	LoadLevel(game ref as tGame, level as integer, pac ref as tPac, sprites ref as tTile[])
	i		as integer
	t		as tTile
	w		as string
	p		as tPos2d
	c		as tPos2d
	max		as tPos2d
	a		as tPos2d
	x		as integer
	y		as integer
	id		as integer
	s 		as string
	tiles	as tTile[]
	e		as integer
	m		as string
	n		as tConnect

	select level
		case 0
			s = "$=Y$;Y$<Y$9]$:]#:Y+;]*;\$:\$9\$8\$7\$6\+:Z$9Z$8Z$7Z,6Z-6Y*6X$5\,4\-4[*4Z$5X$4X$3X$2X$1X$0X$/X$.X$3Z$2Z$1Z$0Z$/Z$.Z#-Z,-X--^--_--`--[--\--]+-a$+a$*a$)a$'a$(a$,a$$a$%a$&a,#a-#`-#_-#^-#]-#\-#[-#Z-#Y##X$$X$%X$&X$'X$(X$)X$*X++X$?Y$@Y$AY-7c-7b-7a-7`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bA8_A8`A8aA9^A:^A;^A;[A:[A9[A8[A7[A6[A5ZA3VA5VA6VA7VA8VA9HA9IA9JA9KA9LA9MA9NA9OA9PA9QA9SA9UA6NA6MA6LA6KA6JA6IA6HA6GA6FA5OA4OA3OA2OA1TA1UA0SA4YA3YA2YA1YA0YA/YA.YA-YA+YA)YA(YA*YA%YA&YA'YA$ZA$[A$\A$]A$^A$_A%`A&`A(`A)`A*`A,_A,^A,]A,\A,[A,ZA,XA,WA,VA,UA,TA-SA.SA/SA1FA5FA4FA3FA2F@0F@,Y@,`@,S@$Y@$`@9FA9GA8FA7FA6EA6DA6CA6BA6AA6@A6?A6>A6=A6<A6;@6:A5:A4:@3:-2:@[email protected],A8*A8)A8(A8'A8%A8&A2V-7d-7e-7f-7g-7h-7i-7j$8k$9k$Ck$:k$;k$<k$=k$>k$?k$@k$Ak$Ck$Bk-Dj-Di-Dh-Dg-Df-De-Dd-Dc-Db-Da-D`-D_-D^-D]-D\-D[-DZ*DY$CY$BY+Dk,7k@CZ@8jAC[AC]AC_AC`ACaACbACdACeACfACgAChACiAAZABZA:jA<jA=jA>jA?jA@jAAjABjA8cA8dA8eA8fA8gA8hA8i<Cj@8^A<^A=^A>^A?^A@^AA^AB^@C^A9jA+`A1OA8+.93.92.91.90.94.9/.9..9-.9,.9+.9*.9).9(.9'.9&.9%.9$07$07%07&07'07(07)07*07+07,07-07.07/070071073072D'`D4VD55D8/A0NA0MA0LA0KA0JA0IA0HA0GC9_A39A38A37A36A9T-:T-:S-8R$>YA;jAC\DCc><HA9RB9V"
			m = "543,541 "
		endcase
		case default
			Message("Invalid level : "+str(level))
		endcase
	endselect


// Load tiles
	max.x = -9999999
	max.y = -9999999

	for i=1 to len(s) step 3
		w = mid(s, i, 3)
		t.typ = asc(mid(w, 1, 1))-35
		if t.typ > sprites.length
			Message("Invalid type:"+str(t.typ))
		endif
		select t.typ
			case TILE_STAR
				id = CloneSprite(game.stars.slot)
				game.stars.id.insert(id)
				game.stars.count = game.stars.id.length
				game.stars.total = game.stars.count
				SetSpriteVisible(id, 1)
				FixSpriteToScreen(id, 1)
				SetSpritePosition(id, GetVirtualWidth() - ((game.stars.id.length + 1) * 16), 0)
				t.id = CloneSprite(sprites[t.typ].id)
				SetSpriteDepth(t.id, 100)
			endcase
			case TILE_TITLE
				t.id = game.title
			endcase
			case TILE_PAC
				t.id = pac.id
				SetSpriteAngle(t.id, GetSpriteAngle(sprites[t.typ].id))
				SetSpriteFlip(t.id, GetSpriteFlippedH(sprites[t.typ].id), GetSpriteFlippedV(sprites[t.typ].id))
				SetSpriteDepth(t.id, 5)
			endcase
			case default
				t.id = CloneSprite(sprites[t.typ].id)
				SetSpriteDepth(t.id, 100)
			endcase
		endselect
		FixSpriteToScreen(t.id, 0)
		a.x = (asc(mid(w, 2, 1))-35)
		a.y = (asc(mid(w, 3, 1))-35)
		if a.x > max.x :	max.x = a.x : endif
		if a.y > max.y : max.y = a.y : endif
		p.x = a.x * 16
		p.y = a.y * 16
		SetSpritePosition(t.id, p.x, p.y)
		SetSpriteVisible(t.id, 1)
		t.name = sprites[t.typ].name
		tiles.insert(t)
	next


// Make a grid
	game.grid.length = max.y
	for y=0 to max.y
		game.grid[y].length = max.x
	next

	for i=0 to tiles.length
		t = tiles[i]
		c.x = GetSpriteX(t.id)/16
		c.y = GetSpriteY(t.id)/16
		if t.typ < 24
			game.grid[c.y, c.x].typ = GRID_WALL
		else
			select t.typ
				case TILE_FEAST
					game.grid[c.y, c.x].typ = GRID_FEAST
					game.grid[c.y, c.x].id = t.id
				endcase
				case TILE_SNACK
					game.grid[c.y, c.x].typ = GRID_SNACK
					game.grid[c.y, c.x].id = t.id
				endcase
				case TILE_END
					game.grid[c.y, c.x].typ = GRID_END
					game.grid[c.y, c.x].id = t.id
					e = t.id
				endcase
				case TILE_STAR
					game.grid[c.y, c.x].typ = GRID_STAR
					game.grid[c.y, c.x].id = t.id
				endcase
			endselect
		endif
	next

	c.x = (GetVirtualWidth() * .5) - (GetSpriteWidth(game.title) / 2)
	c.y = (GetVirtualHeight() * .7) - (GetSpriteHeight(game.title) / 2)

	p.x = GetSpriteX(game.title)
	p.y = getSpriteY(game.title)

	SetSpritePosition(game.water, p.x - c.x, max.y * 16 + 16)

	SetViewOffset(-(GetVirtualWidth()/2-GetSpriteX(e)), -(GetVirtualHeight()*.8-GetSpriteY(e)))


// Load connections
	for i=1 to CountStringTokens(m, " ")
		w = GetStringToken(m, " ", i)
		id = tiles[val(GetStringToken(w, ",", 1))].id
		n.pos.x = GetSpriteX(id)
		n.pos.y = GetSpriteY(id)
		n.obj = Tiles[val(GetStringToken(w, ",", 2))]
		SetSpriteposition(id, -10000, -10000)
		SetSpriteVisible(id, 0)
		game.connect.insert(n)
	next

endfunction tiles

function winDeleteParticles(pac ref as tPac)
	if pac.win <> 0
		DeleteParticles(pac.win)
		pac.win = 0
	endif
endfunction

function SplodePac()
endfunction

function	WinPac(pac ref as tPac)
	i as integer
	if pac.win = 0
		pac.win = CreateParticles(GetSpriteXByOffset(pac.id), GetSpriteYByOffset(pac.id))
		SetParticlesAngle(pac.win, 360)
		SetParticlesImage(pac.win, pac.star)
		SetParticlesRotationRange(pac.win, 30, 60)
		SetParticlesLife(pac.win, 2)
		SetParticlesActive( pac.win, 1 )
		SetParticlesFrequency( pac.win, 60 )
		SetParticlesVelocityRange( pac.win, 5, 10 )
		SetParticlesVisible( pac.win, 1 )
		SetParticlesSize(pac.win, 8)
		SetParticlesDepth(pac.win, 50)
		AddParticlesColorKeyFrame( pac.win, 0, 0xff, 0xff, 0xff, 0xff )
		AddParticlesColorKeyFrame( pac.win, 2, 0, 0, 0, 0 )
       	For i=0 to 40
            UpdateParticles(pac.win, 0.02)
        Next i
	endif
endfunction
